MANUAL DEL USUARIO • DEFENDER
23
(1) Arm Anchor Point B
(2) Fixing point suspension
(3) Attachment point one arm A
(4) Point mounting 2 Arm A
(5) spacer nut and bolt (17/12 * 29 mm, M12 * 60 mm)
(6) spacer nut and bolt (17/12 * 72 mm, M12 * 110 mm)
1. Set 2 and 3 using 5
2. Set 1 and 4 using 6
