4
Step 3
Attach Seat Plate (D) to the bottom of the Seat Cushion
(F) (with the front of the seat plate facing the front of
seat cushion). Attach by using 1-1/2” Screws (I) for the
front holes of the Seat Plate (D) and 1” Screws (H) for
the rear holes of the Seat Plate (D) and tighten screws.
*Note: Tighten the screws completely.
H
I
F
D
N
