Serta 49347 - Page 5

5
Step 4
Insert Levers (D1 & D2) of Seat Plate (D) to the pre-attached
cable lever receivers on the underside of Seat Cushion (F).
Push down the key on the receivers to pull out the levers.
*Note: Fix the cable for the seat plate into the plastic clips
attached to the bottom of the seat cushion.
D1
D2
F
D
Insert
Assemble t he lever
Push
Disassemble the lever
