PARTS
2/8
Sofa Body
QTY:1
1
Left Facing Arm
QTY:1
Right Facing Arm
QTY:1
2
Pillow
QTY:2
Leg
QTY:4
3
4
4
55 5 5
M10 Washer
(Outer Dim. 45mm)
QTY:4
6 6 6 6
