PARTS AND HARDWARE
Avoid using sharp objects such as a knife to open packaging as you may accidentally damage the upholstery.
2 of 12
M5 Allen Key
1x
M8 Nut
4x
14mm Mini Spanner
x1
M8 x 16mm Bolt
22x
Left Sofa Body
1x
Leg
4x
Metal Cap
4x
Plastic Cap
4x
Sofa Cover
1x
Center Leg
1x
Connecting Bar
2x
Right Sofa Body
1x
11 of 12
Sofa with Armrest
ADJUSTING ARMREST POSITIONS
1.
Standing in front of the unit, lift the armrest to the desired position and secure it in
place by releasing to the sound of a click.
To return to a flat position, lift the armrest all the way up to the end, releasing the
locking mechanism and carefully return to a flat position.
IMPORTANT
During conversion, ensure lifting is done on bottom of armrest.
2.
