ASSEMBLY INSTRUCTIONS
CAUTION: At least two adults are required to safely performing this task.
Other lifting attempts may risk back injury due to large and heavy part(s).
Carefully place all components and hardware on a flat surface.
Place sofa legs as shown below, align metal cap and plastic cap onto the bottom of
metal legs, use Allen key to secure the metal cap, plastic cap and leg with a bolt.
1
10 of 12
3 of 12
Converting to Bed
From sofa or lounge position, lift backrest all the way upwards until the last click is heard
which unlocks the mechanism. Carefully return to a flat position.
Splitback
