CDHD2
42 Operator Panel (HMI)
Warnings History
n : STO Warning
L6: Software Limit Switches are Tripped
Press: Shift
Display: F
Press: Up
Display: n
Press: Up
Display: L6
When displayed in Status mode, multi-character warning codes are displayed
in sequence, in digit 4 only. When displayed in Faults & Info mode, multi-
character codes are displayed as strings.
Since the same warning may have been triggered multiple times, you may
need to press the Up or Down key a number of times before the code
changes. Alternately, press and hold the Up or Down key. The longer you
press the key, the faster the scrolling.
