MWU-31 (H) Installation
14-0083 Universal Bracket for .500" switch
Shown with HDWR 130 Universal Bracket hardware
kit including hard rubber inserts to accommodate
various diameters of mounting locations
Mounting Pushbutton PTT switch
to Universal Bracket (recommend
use of non-marring tool)
The MWU-31 (H) is for semi-custom installations where standardized
brackets may not be applicable.
The Transmitter Unit is to be mounted on the left mirror post in the
same way as the standard MWH-31.
The Pushbutton PTT switch assembly is to be installed on the left
side grip. The inserts provided allow fitment to a variety of grip
diameters.
DC Power
Cable
Pushbutton
PTT Switch
Cable
