15. Installing the power supply – PSU bracket
- select the power supply orientation:
- for ATX power supplies, rotate both the power supply and the
bracket
- for SFX power supplies rotate only the power supply, and orient
PSU bracket like shown on the second picture
- put the power supply on a flat surface
- take the power supply mounting bracket and put in next to the
power supply like shown in the picture
- bottom of the power supply bracket and the power supply should
be on the same level
- screw down the power supply to the bracket using four bolts
- please use the bolts supplied with your PSU, as they vary in
length
