36. Alternative GPU mount – installing the assembly (part 2)
- screw down the upper GPU bracket to the case and the
motherboard standoff like shown on picture
- use countersunk bolts to attach the upper GPU bracket
to the chassis, and use flat head bolt to attach the
bracket to the motherboard standoff
- you can now screw down the GPU bracket following
instructions from step 12
- plug the male end of the riser cable into the
motherboard
