SG SG1 - Single-point Usage Diagram

6
Advice
Diagrammatic View
Hot
water
outlet
Cold water inlet
Cold water valve
Outlet & inlet
distance:13.5cm
Located in mains
electric supply or
outside bathroom
Swing check valve
Single-point Usage
Leakage circuit
breaker & separate
isolating electric
supply switch
Electric supply cable
(hidden cable)
