ASSEMBLY
Ensure you have the following components before use:
1. TROLLEY JACK CHASSIS
2. PUMPING HANDLE IN TWO PARTS
OPERATION
USING THE TROLLEY JACK
1. Turn the handle fully clockwise to close the release valve, and
pump the handle to raise the saddle until it reaches the vehicle
lifting point.
2. Ensure that the saddle is directly below the lifting point and
there are no obstructions to prevent a proper lift. Keep all per-
sons at a safe distance before continuing to pump the handle
to raise the vehicle.
3. Position axle stands directly beneath suitable supporting points
under the vehicle, before gently twisting the handle anticlock-
wise.
4. Carefully lower the vehicle onto the axle stands, checking con-
stantly, that the vehicles supporting point rests properly and
cleanly on the axle stand, and that the stand is stable before all
the weight is loaded onto it.
5. Completely remove the jack from the vehicle.
NOTE:
The trolley jack may move ever so slightly
during the lifting process- this is completely
normal, but nevertheless, take care.
WARNING!
Never work on/under a vehicle when
supported only by a trolley jack, it is very
dangerous.
INSPECTION BEFORE EACH USE
Before each use, it’s highly advised to visually inspect this trol-
ley jack.
Abnormalities that should be checked for every time:
• cracked welds
• leaking fluid anywhere on the trolley jack
• bent parts
• missing parts
• loose parts
• damaged parts
This trolley jack should be taken out of service if it is believed
to have been subjected to an abnormal load or shock.
Owner/operators should be aware that repair of this trolley jack
requires specialist attention in the form of suitable repair
equipment and knowledge.
