Side Rail Hole Specification
Espacement des trous des rails latéraux
Seitenschienen-Lochabstand
25
173
15
15
100
400
75
50
25
Threaded
Filetage
Gewinde
Unthreaded
non fileté
ohne Gewinde
M5 x 0.8
5mm
