12
5
7
6
MIN MAX
1
ENGLISH
5 - Make sure that the entire silicone
seal of the lens is adhered to the visor,
otherwise adjust the tension of the lens
using the external adjustment levers and
a coin.
6 – Turn the 2 levers outwards to increase
the tension of the lens (rotate towards
«MAX»).
1 – Locate the visor notch system on each
of the side plates of the visor mechanism.
7 - Remove the protective film from the
PINLOCK® lens before reinstalling the
visor on the helmet.
Clean the lens using mild liquid soap,
lukewarm water and a soft damp rag only.
Allow the lens to dry naturally before
reassembling it.
P I N L O C K V I S O R ®
