TEXTILE PARTS TEXTILE PARTS
DISASSEMBLING THE HELMET INTERIOR
1 - Lift the chin guard. Separate both parts
of the chin strap.
2 - Remove the cheek pads by detaching
the Velcro strip.
3 - Extract the peak, start by removing the
plastic parts of the wrap-around neck roll.
To simplify this step, slide the front part
along the joint before removal.
Detach the front peak support and then
withdraw the peak / wrap-around neck roll
module.
