E N G L I S H
9
TEXTILE PARTS
AA
BB
CC
DD
EE
FF
GG
DISASSEMBLING THE HELMET
INTERIOR
Separate the two parts of the jugular. A
- Remove the chin cover. B
- Release a cheek and remove the Velcro.
C.
- Remove the side part, D
- Do the same with the opposite side
part. E
- Unclip the back of the cap to remove it
from its housing. F
- Finally, unfasten the front cap holder
starting with one side and remove the
cap. G
