Sharkoon DRIVELINK COMBO USB3.0 User Manual

DRIVELINK COMBO USB3.0
3. The device at a glance
A฀–฀฀Connector฀for฀2.5"฀IDE฀HDDs
B฀฀–฀฀Connector฀for฀3.5"฀and฀5.25"฀IDE฀devices
฀฀a฀฀–฀฀Data฀connector฀for฀3.5"฀IDE฀HDDs
฀฀b฀฀–฀฀4-pin฀power฀connector฀for฀3.5"฀IDE฀HDDs
C฀–฀฀Write฀protection฀for฀IDE฀HDDs
฀฀c฀฀–฀฀Write฀protection฀active฀LED
฀฀d฀฀–฀฀Write฀protection฀inactive฀LED
D฀–฀฀Write฀protection฀for฀SATA฀HDDs
฀฀e฀฀–฀฀Write฀protection฀active฀LED
฀฀f฀–฀฀Write฀protection฀inactive฀LED
E฀฀–฀฀฀Power฀LED
F฀฀–฀฀Connector฀for฀SATA฀devices฀(2.5",฀3.5"฀and฀5.25")
G฀฀–฀฀On/off฀switch
A฀฀–฀฀Connector฀for฀SATA฀devices฀(2.5",฀3.5"฀and฀5.25")
A฀–฀USB3.0฀connector
B฀–฀ISO฀power฀connector
*Note on the write protection:
The write protection can only be enabled/disabled when the
DriveLink Combo USB3.0 is switched off!
2
A
A
B
C
D
E
F
G
a
b
c
d
e
f
A
A
B
