Sharkoon REV300 User Manual

Addressable RGB Control
Through Mainboard
 Steuerung adressierbarer LEDs übers Mainboard
 Carte mère contrôle RVB adressable
 Scheda madre controllo RGB addressable
 Control en la placa base del RGB direccionable
 Controle RGB endereçável da placa-mãe
 Adresseerbare RGB bediening via moederbord
 Kontrola adresowalnych RGB z płytą główną
 Címezhető RGB-vezérlő az alaplapon át

Ovládání adresovatelného osvětlení RGB na základní desce
 Управление адресным RGB через материнскую плату
 Anakart üzerinden adreslenebilir RGB Kontrolü

主機板幻彩
RGB
控制

メインボードアドレス指定が可能な
RGB
制御
16
Manual
Addressable RGB Control
 Manuelle Steuerung adressierbarer LEDs
 Commande RVB adressable manuelle
 Controllo manuale RGB addressable
 Control manual del RGB direccionable
 Controle RGB endereçável manual
 Handmatige adresseerbare RGB bediening
 Ręczne sterowanie adresowalnym RGB
 Kézi címezhető RGB-vezérlő
 Ruční ovládání adresovatelného osvětlení RGB
 Ручное управление адресным RGB
 Manuel adreslenebilir RGB Kontrolü

手動幻彩
RGB
控制

手動によるアドレス指定が可能な
RGB
コントロ ー ル
17
Press reset switch to select dierent modes
Red Green Blue White Yellow Cyan Pink
RGB
Mode 1
RGB
Mode 2
RGB
Mode 3
RGB
Mode 4
RGB
Mode 5
RGB
Mode 6
RGB
Mode 7
RGB
Mode 8
RGB
Mode 9
RGB
Mode 10
RGB
Mode 11
RGB
Mode 12
RGB
Mode 13
Press reset switch for 2 seconds to switch o the LED lights.
When the LED lights are o, press reset switch to switch on the LED lights.
SATA
Addressable RGB LED
Fans / Strips
VDG
Mainboard
Addressable
RGB
Pin Header
V D G
or
+5V D
ADD_HEADER

RESET SW
SATA
Addressable RGB LED
Fans / Strips
RESET SW

RESET SW

Sharkoon REV300 Specifications

General

Type	PC
Material	Tempered glass
Form factor	Tower
Illumination	Yes
Product color	Black
Maximum PSU length	270 mm
Number of 2.5\" bays	5
Number of 3.5\" bays	4
Illumination location	Case fans
Number of 5.25\" bays	0
Maximum CPU cooler height	177 mm
Number of expansion slots	8
Maximum graphics card length	345 mm
Supported motherboard form factors	ATX, EATX, Micro ATX, Mini-ITX
Supported HDD sizes	2.5, 3.5 \
USB 2.0 ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Power supply included	No
Top fans installed	1x 120 mm
Rear fans installed	3x 120 mm
Front fans installed	3x 140 mm
Rear fans diameters supported	120 mm
Front fans diameters supported	140 mm
Front radiator sizes supported	420 mm
Number of front fans supported (max)	3
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	501 mm
Width	238 mm
Height	550 mm
Weight	10400 g
