Sharp 14LK14 - Service Mode Adjustment Categories; Geometric and White Point Adjustments; Sub, Offset, and MTS Adjustments; Feature and IC Option Adjustments

7
14LK14
WHITE POINT
ADJ.
MODE
↓
W.P. RED OFFSET HIGH /
OFFSET BLUE TONE (DRI-R-HI)
↓
W.P. GREEN OFFSET HIGH /
OFFSET BLUE TONE (DRI-G-HI)
↓
W.P.BLUE OFFSET HIGH /
OFFSET BLUE TONE (DRI-B-HI)
↓
W.P. RED MH / STD (DRI-R-MH)
↓
W.P. GREEN MH / STD (DRI-G-MH)
↓
W.P. BLUE MH / STD (DRI-B-MH)
↓
W.P. RED OFFSET ML /
OFFSET RED TONE (DRI-R-ML)
↓
W.P. GREEN OFFSET ML /
OFFSET RED TONE (DRI-G-ML)
↓
W.P. BLUE OFFSET ML /
OFFSET RED TONE (DRI-B-ML)
↓
W.P. RED OFFSET LOW (DRI-R-LO)
↓
W.P. GREEN OFFSET LOW (DRI-G-LO)
↓
W.P. BLUE OFFSET LOW (DRI-B-LO)
SUB
ADJ.
MODE
↓
MAX VOLUME (SUB-VOL)
↓
SUB CONTRAST (SUB-CON)
↓
SUB TINT (SUB-TINT)
↓
SUB COLOUR (SUB-COL)
↓
SUB BRIGHTNESS (SUB-BRI)
↓
SUB SHARPNESS (SUB-SHP)
↓
MAX HOTEL VOLUME (HTL-VOL)
↓
HOTEL PROGRAM NO(HTL-PRG)
↓
BLUE BACK CONTRAST (BB-CON)
↓
OSD GRB REFERENCE (RGB)
↓
BLACK LEVEL OFFSET R(CUT-R)
↓
BLACK LEVEL OFFSET G(CUT-G)
↓
CATHODE DRIVE LEVEL(CDL)
AGC &
GEOMETRIC
MODE
↓
AGC TAKE OVER POINT (AGC)
↓
VERTICAL SLOPE (V-LIN)
↓
VERTICAL AMP (V-AMP)
↓
VERTICAL SHIFT (V-CENT)
↓
VERTICAL ZOOM (V-ZOOM)
↓
HORIZONTAL SHIFT (H-CENT)
↓
EAST-WEST WIDTH (H-SIZE)
↓
HORIZONTAL PARALLELOGRAM (EW//)
↓
EAST-WEST PARABOLA / WIDTH (PARA)
↓
EAST-WEST UPPER CORNER
PARABOLA (COR(U))
↓
EAST-WEST LOWER CORNER
PARABOLA (COR(L))
↓
EAST-WEST TRAPEZIUM (TRAPE)
↓
HORIZONTAL BOW (HB)
↓
S-CORRECTION (S-COR)
AGC & WHITE POINT SUB
GEOMETRIC ADJ. ADJ.
MODE MODE MODE
OFFSET
ADJ.
MODE
FEATURE IC MTS
OPTION OPTION ADJ.
MODE MODE MODE
SERVICE MODE
(1) In the Service Mode, Key is used to select the mode in the following oreder.
