Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
35
14SL30
21SL40, 21SL70
R2070 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2101 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2102 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2201 VRD-RA2EE331J J 330 1/4W Carbon AA
R2501 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2503 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R2504 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2505 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2506 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2507 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R2508 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R2509 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R2601 VRD-RA2BE470J J 47 1/8W Carbon AA
R5302 VRD-RA2BE123J J 12k 1/8W Carbon AA
R5305 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R5306 VRS-CY1JF393J J 39k 1/16W M-Ox. AA
R5307 VRS-RA2BE102J J 1.0k 1/8W Carbon AA
SWITCHES
S2501 QSW-K0079GEZZ J Power AB
S2502 QSW-K0079GEZZ J Vol-Down AB
S2503 QSW-K0079GEZZ J Vol-Up AB
S2504 QSW-K0079GEZZ J Ch-Down AB
S2505 QSW-K0079GEZZ J Ch-Up AB
S2506 QSW-K0079GEZZ J Menu AB
MISCELLANEOUS PARTS
å RY751 RRLYU0045CEZZ J Relay
å F701 QFS-C3229CEZZ J Fuse, 3.15A (125V) AD
FB602 RBLN-0037CEZZ J Ferrite Bead AB
FB603 RBLN-0037CEZZ J Ferrite Bead AB
FB701 RBLN-0037CEZZ J Ferrite Bead AB
FB702 RBLN-0037CEZZ J Ferrite Bead AB
FB703 RBLN-0037CEZZ J Ferrite Bead AB
å FB704 RBLN-0037CEZZ J Ferrite Bead AB
FB752 RBLN-0037CEZZ J Ferrite Bead AB
FB753 RBLN-0037CEZZ J Ferrite Bead AB
FB754 RBLN-0037CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
P401 QPLGN0561CEZZ J Plug, 5-pin (GBN) AB
P601 QPLGN0603CEZZ J Plug, 6-pin (K) AB
P651 QPLGN0361CEZZ J Plug, 3-pin AB
P701 QPLGN0269GEZZ J Plug, 2-pin (P) AB
P702 QPLGN0207CEZZ J Plug, 2-pin (M) AA
P751 QPLGN0461CEZZ J Plug, 4-pin (YBN) AB
P998 QPLGN0461CEZZ J Plug, 4-pin (E) AB
P999 QPLGN0461CEZZ J Plug, 4-pin (D) AB
P2001 QPLGN0561CEZZ J Plug, 5-pin AB
P5301 QPLGN0461CEZZ J Plug, 4-pin (S) AB
RMC2601 RRMCU0222CEZZ J R/C Receiver AL
or
RRMCU0216CEZZ
RDA501 PRDAR0103GJFW X Heat Sink, for IC501 AN
RDA602 PRDAR0216PEFW R Heat Sink, for Q602 AE
RDA701 PRDAR0260PEFW R Heat Sink, for IC701 AH
RDA754 PRDAR0160PEFW X Heat Sink, for D754 AF
RDA5301 PRDAR0258PEFW R Heat Sink, for IC5301 AG
TAN901 QTANJ0253CEZZ J Terminal
LHLDP1042PE00 R Holder AG
LHLDW1002PEZZ R Holder AB
LX-BZ0086TAFD J Screw AA
LX-BZ3100CEFD J Screw AA
LX-TZ3004CEFD J Screw AA
PWB-A: DUNTK9882WEV1 (21SL40)
MAIN UNIT (Continued)
PWB-A: DUNTK9882WEV0 (14SL30)
PWB-A: DUNTK9882WEV2 (21SL70)
MAIN UNIT
TUNER
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTU115B8025AM X Tuner BA
INTEGRATED CIRCUITS
IC101 VHiKA78S05P-1 J KA78S05P AD
çå IC201 RH-iX3253CEZZ J TA1268AN AV
IC351 VHiTDA7056A-1 J TDA7056A (14SL30) AP
å IC501 VHiTA8403K/-1 J TA8403K AL
å IC701 VHiSTRF6654-1 J STRF6654 AX
å IC702 RH-FX0008GEZZ J PC123FY8 AE
å IC703 VHiMiP0254/-1 X MIP0254
å IC704 RH-FX0008GEZZ J PC123FY8 AE
å IC751 VHiKA7809Pi-1 M KA7809PI AE
or
VHiTA7809S/-1
å IC752 VHiKA7809Pi-1 M KA7809PI AE
or
VHiTA7809S/-1
å IC753 VHiSE115N//-1 J SE115N AF
IC2001 RH-iX3256CEZZ J TMPA8701CMF142 AX
IC2040 VHiPST994C/-1 J PST994C AD
IC2101 VHiM24C01B/-1 J M24C01-BN6 AF
or
RH-iX2447CEN1
IC3001 VHiCXA2074Q-1 J CXA2074Q (21SL70) AY
IC5301 VHiAN5276//-1 J AN5276 (21SL70) AR
TRANSISTORS
You can substitute "VC2SC2462-C-1" for "VS2SD601AR/-1".
Q201 VS2SC2735//1E J 2SC2735 AC
Q301 VS2SD601AR/-1 J 2SD601AR (21SL70) AC
Q351 VS2SC2462-C-1 J 2SC2462 (14SL30) AB
Q401 VS2SD601AR/-1 J 2SD601AR AC
Q402 VS2SB709AR/-1 J 2SB709AR AC
Q403 VS2SD601AR/-1 J 2SD601AR AC
Q404 VS2SB709AR/-1 J 2SB709AR AC
Q451 VS2SB709AR/-1 J 2SB709AR AC
Q601 VS2SC2482//-1 J 2SC2482 AD
or
VS2SC2610/-1E
å Q602 VS2SD2586//1E J 2SD2586 AM
Q752 VS2SC3198-G-1 J 2SC3198(G) AA
Q753 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q951 VS2SD601AR/-1 J 2SD601AR (21SL70) AC
Q952 VS2SD601AR/-1 J 2SD601AR (21SL70) AC
Q953 VS2SD601AR/-1 J 2SD601AR (21SL70) AC
Q961 VS2SD601AR/-1 J 2SD601AR (21SL70) AC
Q962 VS2SD601AR/-1 J 2SD601AR (21SL70) AC
Q963 VS2SD601AR/-1 J 2SD601AR (21SL70) AC
Q2001 VS2SD601AR/-1 J 2SD601AR AC
Q2002 VS2SD601AR/-1 J 2SD601AR AC
Q2060 VS2SC2462-C-1 J 2SC2462(C) AB
DIODES
D51 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D52 RH-EX0676GEZZ J Zener Diode, 33V AA
D103 VHD1SS119//-1 J Diode AB
D401 VHD1SS119//-1 J Diode AB
D402 RH-EX0092CEZZ J Zener Diode, 3.9V AB
D454 RH-EX0103CEZZ J Zener Diode, 5.6V AB
D455 VHD1SS119//-1 J Diode AB
D501 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D502 RH-DX0131CEZZ J Diode AC
D641 RH-EX0631GEZZ J Zener Diode, 9.1V AA
çå D651 RH-DX0131CEZZ J Diode AC
çå D652 VHD1SS119//-1 J Diode AB
çå D653 RH-EX0091CEZZ J Zener Diode, 22V AB
