Sharp 2020215A0343 Service Manual

Section 1 Basic Information
Product Specification – Compact Air
Conditioners Chassis – COMII
Model
AF-S100RX
AF-S120RX
AF-S125RX
ENERGY STAR Yes Yes Yes
Performance
-
-
-
BTU (Cool) 10,000 12,000 12,000
BTU (Heat) - - -
Dehumidification (Pints/Hour) 3.0 3.8 3.8
Cool Area (Sq. Ft.) 505 650 650
EER 10.8 10.8 10.8
Electrical
-
-
-
Volts/Hertz 115V/60Hz 115V/60Hz 115V/60Hz
Amps (Cool) 8.8 10.2 10.2
Amps (Heat) - - -
Amps (Cool) 925 1110 1110
Amps (Heat) - - -
Length of Power Cord 6' (6.5') 6' (6.5') 6' (6.5')
NEMA Plug Type LCDI,5-15P LCDI, 5-15P LCDI, 5-15P
Features
-
-
-
Controls Electronic El
ectronic Electronic
Fan Speeds (Cool/Fan/Heat) 3/3/- 3/3/- 3/3/-
Low Voltage Start-Up Yes Yes Yes
Auto Cool Function Yes Yes Yes
Energy Save Yes Yes Yes
Sleep Mode - - -
Filter Check - - -
24 Hour On/Off Timer Yes Yes Yes
Remote control Full Function Full Function Full Function
Air CFM (High/Med/Low) 317.5/276.4/2
35.2 299.9/264.6/223.
4 299.9/264.6/223.4
Air Direction Control 8-Way 8-Way 8-Way
Fresh Air/Exhaust Vent/Closed Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes
Filter type Anti-Bact Mesh An
ti-Bact Mesh Anti-Bact Mesh
Filter Access Tilt-Out
Tilt-Out Tilt-Out
Slide-Out Chassis - - -
Cabinet Louvers Yes Yes Yes
Rear Grill - - -
Window Mounting Kit
Pleated Quick
Mount
Pleated Quick
Mount
Pleated Quick
Mount
Dimensions (in)
-
-
-
A-Cabinet Height 14.4" 14.4" 14.4"
B-Cabinet Width 19" 19" 19"
C-Cabinet Depth (with Front) 19-3/4"(22-
5/8") 19-3/4"(22-5/8") 19-3/4"(22-5/8")
D-Window Height (Min.) 15 1/2" 15 1/2" 15 1/2"
E-Window Width (Min./Max.) 22/36 22/36 22/36
F-Max. Wall Thickness N/A N/A N/A
Carton Height 16.5" 16.5" 16.5"
Carton Width 22.2" 22.2" 22.2"
Carton Depth 24.8" 24.8" 24.8"
Unit Weight (Lbs.) 58.4 65.3 65.3
Shipping Weight (Lbs.) 70.8 77.6 77.6
UPC 0-12505- 66301-5 66300-2 66303-9
1-9

Sharp 2020215A0343 Specifications

General

Brand	Sharp
Model	2020215A0343
Category	Air Conditioner
Language	English
