Sharp 2020215A0343 Service Manual

Section 1 Basic Information
Product Specification – Mini Compact
Air Conditioners Chassis – MSII
Model
AF-S60RX
AF-S80RX
AF-S85RX
ENERGY STAR Yes Yes Yes
Performance
-
-
-
BTU (Cool) 6,000 8,000 8,000
BTU (Heat) - - -
Dehumidification (Pints/Hour) 1.3 1.7 1.7
Cool Area (Sq. Ft.) 215 360 360
EER 10.7 10.8 10.8
Electrical
-
-
-
Volts/Hertz 115V/60HZ 115V/60HZ 115V/60HZ
Amps (Cool) 5.4 7.0 7.0
Amps (Heat) - - -
Amps (Cool) 560 740 740
Amps (Heat) - - -
Length of Power Cord 6'(6.5') 6'(6.5') 6'(6.5')
NEMA Plug Type LCDI,5-15P LCDI,5-15P LCDI,5-15P
Features
-
-
-
Controls Electronic El
ectronic Electronic
Fan Speeds (Cool/Fan/Heat) 3/3/- 3/3/- 3/3/-
Low Voltage Start-Up Yes Yes Yes
Auto Cool Function Yes Yes Yes
Energy Save Yes Yes Yes
Sleep Mode - - -
Filter Check - - -
24 Hour On/Off Timer Yes Yes Yes
Remote control Full Function Full Function Full Function
Air CFM (High/Med/Low) 176.4/152.9/1
23.5 223.4/188.2/158.
8 223.4/188.2/158.8
Air Direction Control 4-Way 8-Way 8-Way
Fresh Air/Exhaust Vent/Closed
No/No/Yes No/No/Yes No/No/Yes
Filter type Anti-Bact Mesh An
ti-Bact-Mesh Anti-Bact-Mesh
Filter Access Tilt-Out
Tilt-Out Tilt-Out
Slide-Out Chassis - - -
Cabinet Louvers Yes Yes Yes
Rear Grill - - -
Window Mounting Kit
Pleated Quick
Mount
Pleated Quick
Mount
Pleated Quick
Mount
Dimensions (in)
-
-
-
A-Cabinet Height 12-1/2" 12-1/2" 12-1/2"
B-Cabinet Width 18-1/2" 18-1/2" 18-1/2"
C-Cabinet Depth (with Front) 14"(1
6 3/8") 14"(16 3/8") 14"(16 3/8")
D-Window Height (Min.) 14" 14" 14"
E-Window Width (Min./Max.) 21.5"/34.5" 23" / 36" 23" / 36"
F-Max. Wall Thickness N/A N/A N/A
Carton Height 14.7" 14.7" 14.7"
Carton Width 21.85" 21.85" 21.85"
Carton Depth 18.7" 18.7" 18.7"
Unit Weight (Lbs.) 41.9 47.4 47.4
Shipping Weight (Lbs.) 51.8 57.3 57.3
UPC 0-74000- 66298-8 66299-5 66300-8
1-8
