Sharp 21LT-45SES User Manual

24
AK - 44
CHASSIS
Default Values
Register Parameter Notes
A51EFS13X191 A51ELD032X001
APR
APR Threshold 10 4
BRI
Factory Setting Brightness 31 31
CON
Factory Setting Contrast 49 49
COL
Factory Setting Colour 26 26
SHA
Factory Setting Sharpness 6 6
HUE
Factory Setting Hue 31 31
VOL
Factory Setting Volume 9 9
WR-R
White Point Adjust for Red (RGB mode) 48 30
WG-R
White Point Adjust for Green (RGB
mode)
53 40
WB-R
White Point Adjust for Blue (RGB mode) 37 40
FMP1
FM Prescaler when AVL is OFF STEREO ONLY 11 11
NIP1
NICAM Prescaler when AVL is OFF STEREO ONLY 25 25
SCP1
SCART Prescaler when AVL is OFF 11 11
SEC1
SCART Prescaler when AVL is OFF for
SECAM L/L’ MONO
11 11
FMP2
FM Prescaler when AVL is ON 16 16
NIP2
NICAM Prescaler when AVL is ON STEREO ONLY 37 37
SCP2
SCART Prescaler when AVL is ON STEREO ONLY 17 17
SEC2
SCART Prescaler when AVL is ON for
SECAM L/L’ MONO
17 17
F1H
High Byte of crossover frequency for
VHF1-VHF3
Meaningful for only PLL
Tuner
See “15.1 Service Registers
Updating regarding the Tuner”
on Page 27.
F1L
Low Byte of crossover frequency for
VHF1-VHF3
Meaningful for only PLL
Tuner
See “15.1 Service Registers Updating
regarding the Tuner”
on Page 27.
F2H
High Byte of crossover frequency for
VHF3-UHF
Meaningful for only PLL
Tuner
See “15.1 Service Registers Updating
regarding the Tuner”
on Page 27.
F2L
Low Byte of crossover frequency for
VHF3-UHF
Meaningful for only PLL
Tuner
See “15.1 Service Registers Updating
regarding the Tuner”
on Page 27.
BS1
Band Switch Byte for VHF1 Meaningful for only PLL
Tuner
See “15.1 Service Registers Updating
regarding the Tuner”
on Page 27.
BS2
Band Switch Byte for VHF3 Meaningful for only PLL
Tuner
See “15.1 Service Registers Updating
regarding the Tuner”
on Page 27.
BS3
Band Switch Byte for UHF Meaningful for only PLL
Tuner
See “15.1 Service Registers Updating
regarding the Tuner”
on Page 27.
CB
Control Byte Meaningful for only PLL
Tuner
See “15.1 Service Registers Updating
regarding the Tuner”
on Page 27.
OP1
Option 1 (see the Option List) x x
OP2
Option 2 (see the Option List) x x
OP3
Option 3 (see the Option List) x x
OP4
Option 4 (see the Option List) x x
OP5
Option 5 (see the Option List) x x
TX1
Teletext Option 1 (see the Option List) x x
GEOM
Geometry Menu See Geometry Table on Page 25.
OP8
Not used x x
