21S-FX10F/10S/10N/10U
3 – 21
10. SHOCK TEST CHECKING
NO ADJUSTMENT POINT ADJUSTMENT CONDITION / PROCEDURE WAVEFORM OR REMARKS
14 COLOUR SYSTEM (1) Receive the " PAL COLOUR BAR" signal, press the COLOUR SYSTEM
key to select modes except PAL, check the COLOUR is not working properly..
Then, select the " PAL" mode. Check again its colour so that it is working properly..
(2) Receive "SECAM COLOUR BAR" signal, press COLOUR SYSTEM
key to select modes except SECAM, check the COLOUR is not working properly.
Then, select the "SECAM" mode. Check again its colour so that it is working
properly.
(3) Receive "NTSC 4.43" signal, press COLOUR SYSTEM key to select
modes except NTSC 4.43, check the COLOUR is not working properly.
Then, select the "NTSC 4.43" mode. Check again its colour so that it is working
properly.
(4) Receive "NTSC 4.43/3.58 COLOUR BAR" signal thru AV, press COLOUR
SYSTEM key to select modes except N4.43/3.58, check the COLOUR is not
working properly. Then, select the "NTSC 4.43/3.58" mode. Check again its
colour so that it is working properly..
15 SOUND SYSTEM (1) Receive "PAL-D/K" signal, press the "SOUND SYSTEM"
to select B/G, I. Check the sound output is not working properly.
Select D/K and check the sound output to make sure it is working properly.
(2) Receive "PAL-I" signal, press the "SOUND SYSTEM"
to select B/G, D/K. Check the sound output is not working properly.
Select I and check the sound output to make sure it is working properly.
(3) Receive "PAL-B/G" signal, press the "SOUND SYSTEM"
to select I, D/K. Check the sound output is not working properly.
Select B/G and check the sound output to make sure it is working properly.
16 M.P.IN (1) Turn up the volume control to maximum, make sure the sound is heard from
speakers.
*Note:
CHECKING
(2) Make sure M.P. IN feature is set to ON.
For model with M.P.in featur
e
(3) Plug in stereo cable in M.P.In terminal.
(4)
'M.P.IN' OSD will appear at bottom right corner TV screen, RF channel sound will
be switched to M.P.In sound.
(5) Check the sound is normal.
17 NOISE MUTE (1) Receive mono-tone signal.
CHECKING (2) Turn up the volume control to maximum, make sure the sound is
heard from the speakers. Then put the unit in no signal state.
(3) Check the sound mute is effective..
(4) Finally turn sound level of CTV to minimum.
18 OSD LANGUAGE (1) Check OSD LANGUAGE quantity and type for respective model.
QUANTITY CHEC
K
MODEL QUANTITY ENGLISH FRENCH ARAB
21S-FX10F/10S
4
OOO
21S-FX10N/10U
RUSSIA
O
NO ADJUSTMENT POIN
T
ADJUSTMENT CONDITION / PROCEDURE WAVEFORM OR OTHERS
1 SHOCK TEST (1) Hit at the top of TV set for two time.
(2) Check TV set not damage and TV operation operate correctl
y
.
To Next Page
