Sharp 21S-FX10F User Manual

21S-FX10F/10S/10N/10U
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R858 VRS-RG2HC100J+ R 10 0.5W Metal Film
!
R861 VRD-RM2HD224JY AA R 220K 500V Carbon
!
R863 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
R864 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
R865 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
P855 LHLDW1104PEZZ AB R Plug 4Pin (H)
P860 LHLDW1105PEZZ AB R Plug 5Pin (K)
RDA851 PRDAR0248PEFW R Heat Sink for IC851
SC851 QSOCVA023WJZZ AE R Socket , 12Pin
[5] SURROUND UNIT
IC3801 VHINJM2701M-1Y R I.C.
D3801 RH-EX0641GEZZY R Zener Diode 12.35V
C3801 VCE9GA1HW106M+ AB R 10 50V Electrolytic
C3802 VCEA0A1HW106M+ AB R 10 50V Electrolytic
C3803 VCE9GA1HW106M+ AB R 10 50V Electrolytic
C3804 VCKYCY1HB472KY AA R 4.7 50V Ceramic
C3805 VCKYCY1HB223KY AA R 0.22 50V Ceramic
C3806 VCEA0A1HW105M+ R 1000000pf 50V Alminium electrolytic
C3808 VCEA0A1EW107M+ R 100 25V Electrolytic
C3809 VCKYCY1HB103KY AA R 0.01 50V Ceramic
C3810 VCEA0A1HW106M+ AB R 10 50V Electrolytic
C3811 VCEA0A1HW106M+ AB R 10 50V Electrolytic
C3812 VCEA0A1HW106M+ AB R 10 50V Electrolytic
C3815 VCEA0A1HW106M+ AB R 10 50V Electrolytic
C3821 VCKYCY1HB103KY AA R 0.01 50V Ceramic
C3822 VCKYCY1HB103KY AA R 0.01 50V Ceramic
R3802 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R3803 VRD-RM2HD471JY AA R 470 500V Carbon
R3804 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R3805 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
P3801 QPLGN0240FJ00 R Plug
P3802 QPLGNA107WJZZ R Plug
JC3002 QJUM-0001AJFWY R Jumper Wire
[6] MISCELLANEOUS PARTS
!
ACC701 QACCZA082WJPZ R AC Cord ( 21S-FX10F )
QACCBA051WJN1 R AC Cord ( 21S-FX10S / 21S-FX10N )
QACCZA048WJN1 R AC Cord ( 21S-FX10U )
SP301 VSP9050PA05YA R SPEAKER
QCNW-G288WJPZ R SP WIRE (+--+)
QCNW-A343WJZZ AD R H-WIRE
QCNW-A788WJPZ AD R K-WIRE
[7] SUPPLIED ACCESSORIES
RRMCGA547WJSA AN R Infrared Remote Control Unit
TINS-D504WJN1 - R Operation Manual E / F ( 21S-FX10F / 21S-FX10S )
TINS-D505WJN1 - R Operation Manual RU / AR ( 21S-FX10F / 21S-FX10S )
TINS-D568WJZZ - R Operation Manual E / A ( 21S-FX10N )
TINS-D569WJZZ - R Operation Manual F / R ( 21S-FX10N )
TGAN-A797WJZZ - R G-Cards ( 21S-FX10N )
TINS-D538WJZZ - R Operation Manual EN / UK ( 21S-FX10U )
UBATUA004WJZZ - R Battery
[4] CRT UNIT
