Sharp 21V-FS700S - Page 81

21V-FS700S
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1054 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1055 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1056 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1057 VRD-RA2BE151JY AA R 150 1/8W Carbon
R1058 VRD-RA2BE151JY AA R 150 1/8W Carbon
R1059 VRD-RA2BE151JY AA R 150 1/8W Carbon
R1078 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1079 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R3001 VRS-CY1JF750JY AA R 75 1/16W Metal Oxide
S701 QSW-PA003WJZZ AG R Switch , POWER
S1001 QSW-KA019WJZZ+ AC R Switch , CH UP
S1002 QSW-KA019WJZZ+ AC R Switch , CH DOWN
S1003 QSW-KA019WJZZ+ AC R Switch , VOL UP
S1004 QSW-KA019WJZZ+ AC R Switch , VOL DOWN
S1005 QSW-KA019WJZZ+ AC R Switch , MENU
!
F701 QFS-C3225CEZZ AC R Fuse , 3.15A 250V
FH701 QFSHD1013CEZZ+ AC R Fuse Holder
FH702 QFSHD1014CEZZ+ AC R Fuse Holder
J3 VW7UGB-190KK R Jumper Wire
J351 QJAKJA018WJZZ R Jack
J401 QJAKGA083WJZZ R Jack
J402 QJAKEA056WJ04 R Jack
J403 QJAKEA056WJ09 R Jack
J404 QJAKEA070WJ02 R Jack
J405 QTANJA080WJZZ R Jack
JA435 QJUM-0001AJFWY R Jumper Wire
JA504 QJUM-0001AJFWY R Jumper Wire
JA505 QJUM-0001AJFWY R Jumper Wire
P302 QPLGN0461CEZZA AB R Plug , 4Pin (S)
P601 QPLGN0660CEZZ AC R Plug , 6Pin (F)
P602 LHLDW1104PEZZ AB R Plug
P701 QPLGN0260CEZZ AC R Plug ,2Pin (M)
P702 QPLGN0269GEZZ AB R Plug ,2Pin
P1001 LHLDW1105PEZZ AB R Plug
P1002 QPLGNA110WJZZ AB R Plug
RMC1001 RRMCUA022WJZZ AG R Remote Receiver
RDA301 PRDARA418WJFW AC R Heat Sink for IC301
RDA392 PRDARA181WJFW R Heat Sink for D392
RDA501 PRDARA545WJFW AD R Heat Sink for IC501
RDA602 PRDARA361WJFW R Heat Sink for Q602
RDA604 PRDARA361WJFW R Heat Sink for Q604
RDA701 PRDARA119WJFW AF R Heat Sink for IC701
RDA751 PRDARA615WJFW R Heat Sink for IC751
RDA752 PRDARA167WJFW R Heat Sink for IC752
[4] CRT UNIT
IC851 VHITDA6107A-1 R I.C.
D851 RH-DX0443CEZZY R Diode
D852 RH-DX0443CEZZY R Diode
D853 RH-DX0443CEZZY R Diode
C851 VCKYPA1HB561K+ AA R 560p 50V Ceramic
C852 VCKYPA1HB391K+ AA R 390p 50V Ceramic
C854 RC-KZ018JCEZZ R 10000pf 250V Porcelain
C856 VCKYPA2HB102K+ AB R 1 500V Ceramic
C861 VCKYPA2HB561K+ AB R 560p 500V Ceramic
C862 VCKYPA2HB102K+ AB R 1 500V Ceramic
C863 VCKYPA2HB102K+ AB R 1 500V Ceramic
C851 RC-FZA295WJZZ+ R 0.082u 250v Metalic Plastic Film
C852 VCEA0A2EW106M+ AB R 10 250V Electrolytic
R851 VRD-RM2HD101JY AA R 100 500V Carbon
R852 VRD-RM2HD101JY AA R 100 500V Carbon
R853 VRD-RM2HD101JY AA R 100 500V Carbon
R854 VRC-MA2HG152KY R 1.5K 0.5W Solid
R855 VRC-MA2HG152KY R 1.5K 0.5W Solid
R856 VRC-MA2HG152KY R 1.5K 0.5W Solid
R858 VRS-RG2HC100J+ R 10 0.5W Metal Film
!
R861 VRD-RM2HD224JY AA R 220K 500V Carbon
!
R863 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
R864 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
R865 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
P855 LHLDW1104PEZZ AB R Plug 4Pin (H)
P860 LHLDW1105PEZZ AB R Plug 5Pin (K)
RDA851 PRDAR0248PEFW R Heat Sink for IC851
SC851 QSOCVA023WJZZ AE R Socket , 12Pin
[5] MISCELLANEOUS PARTS
!
ACC701 QACCZA091WJPZ R AC Cord
SP301 VSP9050PA05YA R SPEAKER
QCNW-G288WJPZ R SP WIRE (+--+)
QCNW-A343WJZZ AD R H-WIRE
QCNW-A788WJPZ AD R K-WIRE
[3] MAIN UNIT
