Sharp 21v-r70MM - MAIN UNIT Parts List (Continued); Fuses and Fuse Holders; Connectors and Plugs

21V-R70MM
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1023 VRS-CY1JF271JY AA R 270 1/16W Metal Oxide
R1024 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1027 VRS-CY1JF104JY AA R 100K 1/16W Metal Oxide
R1031 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1032 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1034 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1036 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1040 VRD-RA2BE273JY AA R 27K 1/8W Carbon
R1041 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1042 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1043 VRS-CY1JF104JY AA R 100K 1/16W Metal Oxide
R1044 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1045 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1046 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1047 VRS-CY1JF183JY AA R 18K 1/16W Metal Oxide
R1048 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1049 VRS-CY1JF183JY AA R 18K 1/16W Metal Oxide
R1051 VRD-RA2BE473JY AA R 47K 1/8W Carbon
R1054 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1055 VRD-RA2BE332JY AA R 3.3K 1/8W Carbon
R1056 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1058 VRD-RA2BE103JY AA R 10K 1/8W Carbon
R1061 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
R1062 VRS-CY1JF105JY AA R 1M 1/16W Metal Oxide
R1063 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1064 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1065 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1066 VRS-CY1JF561JY AA R 560 1/16W Metal Oxide
R1072 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
R1073 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1074 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1076 VRD-RA2BE102JY AA R 1K 1/8W Carbon
R1081 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1096 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1097 VRS-CY1JF472JY AA R 4.7K 1/16W Metal Oxide
R1098 VRS-CY1JF104JY AA R 100K 1/16W Metal Oxide
R1801 VRD-RA2BE222JY AA R 2.2K 1/8W Carbon
R1802 VRS-CY1JF124JY AA R 120K 1/16W Metal Oxide
R1850 VRS-CY1JF472JY AA R 4.7K 1/16W Metal Oxide
R1851 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
R1852 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
R1853 VRS-CY1JF221JY AA R 220 1/16W Metal Oxide
R1854 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1855 VRD-RA2BE122JY AA R 1.2K 1/8W Carbon
R1894 VRD-RA2BE103JY AA R 10K 1/8W Carbon
R1895 VRS-CY1JF473JY AA R 47K 1/16W Metal Oxide
R1896 VRS-CY1JF473JY AA R 47K 1/16W Metal Oxide
S701 QSW-P0612CEZZ R Power Switch
S1001 QSW-K0003AJZZ+ AB R Switch , CH-UP
S1002 QSW-K0003AJZZ+ AB R Switch , CH-DOWN
S1003 QSW-K0003AJZZ+ AB R Switch , VOL-UP
S1004 QSW-K0003AJZZ+ AB R Switch , VOL-DOWN
S1005 QSW-K0003AJZZ+ AB R Switch , MENU
!
F701 QFS-C3225CEZZ AC R Fuse , 3.15A 250V
!
FH701 QFSHD1013CEZZ+ AC R Fuse Holder
!
FH702 QFSHD1014CEZZ+ AC R Fuse Holder
J405 QJAKFA053WJQZ R Jack
P301 QPLGN0241CEZZ AB R Plug , 4Pin (S)
P601 QPLGN0660CEZZ AB R Plug , 6Pin (K)
P602 QPLGN0441CEZZ AB R Plug , 4Pin
P603 QPLGN0341CEZZ AA R Plug , 3Pin
P701 QPLGN0260CEZZ AB R Plug , 2Pin (M)
P702 QPLGN0269GEZZ AB R Plug , 2Pin
P1001 QPLGN0541CEZZ AB R Plug , 5Pin
P1002 QPLGN0541CEZZ AB R Plug , 5Pin (BC)
RDA303 PRDARA172WJFW AB R Heat Sink , IC303
RDA501 PRDARA120WJFW AB R Heat Sink , IC501
RDA601 PRDARA181WJFW AC R Heat Sink , IC601
RDA602 PRDARA361WJFW AF R Heat Sink , Q602
RDA701 PRDARA119WJFW AC R Heat Sink , IC701
RMC1001 RRMCUA022WJZZ AG R Remote Receiver
!
RY701 RRLYJ0089CEZZ AG R Relay
[4] CRT UNIT
Q853 VSBF422++++-2+ R BF422++
Q854 VSBF422++++-2+ R BF422++
Q855 VSBF422++++-2+ R BF422++
Q894 VS2SA1015Y/1E+ AB R 2SA1015Y
D859 VHDHSS4148+-1Y R SS4148+-1
D898 VHDHSS4148+-1Y R SS4148+-1
L851 VP-MK820K0000+ AB R Peaking , 82mH
C851 VCKYPA1HB561K+ AB R 560p 50V Ceramic
C852 VCKYPA1HB331K+ AB R 330p 50V Ceramic
C853 VCKYPA1HB221K+ AB R 220p 50V Ceramic
[3] MAIN UNIT
