Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
53
25K-S100/180/S100/S180
CK25M10,CK25S18
R2063 VRD-MN2BE222J J 2.2k 1/8W Carbon AA
R2064 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R2065 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R2067 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2068 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2070 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2071 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R2101 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2102 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2201 VRD-MN2BE222J J 2.2k 1/8W Carbon AA
R2202 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2203 VRS-CY1JF184J J 180k 1/16W M-Ox. AA
R2211 VRD-MN2BE222J J 2.2k 1/8W Carbon AA
R2212 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2213 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2401 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2402 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2403 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2404 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2501 VRD-MN2BE103J J 10k 1/8W Carbon AA
R2503 VRD-MN2BE273J J 27k 1/8W Carbon AA
R2504 VRD-MN2BE123J J 12k 1/8W Carbon AA
R2505 VRD-MN2BE563J J 56k 1/8W Carbon AA
R2506 VRD-MN2BE563J J 56k 1/8W Carbon AA
R2507 VRD-MN2BE823J J 82k 1/8W Carbon AA
R2508 VRD-MN2BE153J J 15k 1/8W Carbon AA
R2509 VRD-MN2BE272J J 2 7k 1/8W Carbon AA
R2601 VRD-RA2BE331J J 330 1/8W Carbon AA
R3001 VRD-RA2BE221J J 220 1/8W Carbon AA
R3002 VRD-RA2BE221J J 220 1/8W Carbon AA
R3003 VRS-CY1JF105J J 1M 1/16W M-Ox. AA
R3004 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3005 VRS-CY1JF623J J 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302J J 3k 1/16W M-Ox. AA
R3010 VRD-MN2BE392J J 3.9k 1/8W Carbon AA
R3011 VRD-RA2BE102J J 1k 1/8W Carbon AA
R3012 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R3013 VRD-MN2BE104J J 100k 1/8W Carbon AA
R3014 VRD-MN2BE104J J 100k 1/8W Carbon AA
R3015 VRD-RA2BE101J J 100 1/8W Carbon AB
R3016 VRD-MN2BE750J J 75 1/8W Carbon AA
R3017 VRD-RA2BE102J J 1k 1/8W Carbon AA
R3018 VRD-RA2BE102J J 1k 1/8W Carbon AA
SWITCHES
S2501 QSW-K0079GEZZ J Power AB
S2502 QSW-K0079GEZZ J VOL-down AB
S2503 QSW-K0079GEZZ J VOL-up AB
S2504 QSW-K0079GEZZ J CH-down AB
S2505 QSW-K0079GEZZ J CH-up AB
MISCELLANEOUS PARTS
å RY701 RRLYU0036CEZZ J Relay AM
or
RRLYU0038CEZZ AM
å F701 QFS-B4023CEZZ J Fuse, 4A (125V) AC
or
QFS-B4021GEZZ AK
FB601 RBLN-0037CEZZ J Ferrite Bead AB
FB701 RBLN-0037CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
å P602 QPLGN0160FJZZ J Plug, 5-pin(K) AD
P651 QPLGN0361CEZZ J Plug, 3-pin AB
P701 QPLGN0207CEZZ J Plug, 2-pin(M) AA
P702 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
P703 QPLGN0269GEZZ J Plug, 2-pin(P) AB
P901 QPLGN0561CEZZ J Plug, 5-pin(HA) AB
P902 QPLGN0461CEZZ J Plug, 4-pin(S)
P903 QPLGN0561CEZZ J Plug, 5pin(GBN) AB
P2401 QPLGN0561CEZZ J Plug,5-pin AB
RMC2601 RRMCU0227CEZZ J Remote Receiver AK
or
RRMCU0224CEZZ
or
RRMCU0216CEZZ
or
RRMCU0232CEZZ
RDA501 PRDAR0234PEFW R Heat Sink, IC501 AH
RDA604 PRDAR0233PEFW M Heat Sink, Q602 AE
RDA707 PRDAR0026PEFW R Heat Sink, D707 AD
RDA751 PRDAR5072CEFW J Heat Sink, Q751 AC
TAN921 QTANJ0323CEZZ M AV Terminal AF
PWB-A: DUNTK9509WEK2 (25K-S100)
PWB-A: DUNTK9509WEK3 (25K-S180)
PWB-A: DUNTK9509WEK9 (CK25S18)
MAIN UNIT (Continued)
