Ref. No. Part No. « Description Code
C403 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C429 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C433 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C434 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C435 VCEA0A1HW105M+ X 1 50V EL. AB
C436 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C437 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C438 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C439 VCEA0A1HW106M+ X 10 50V EL. AB
C440 VCFYFA1HA224J+ X 0.22 50V Mylar AB
C451 VCQYTA2AA104K+ X 0.1 100V Mylar AB
C452 VCEA0A1EW336M+ X 33 25V EL. AB
C471 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C473 VCCCCY1HH331JY X 330p 50V Ceramic AB
C474 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C475 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C476 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C501 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C502 VCEA0A1VW477M+ X 470 35V EL. AB
C504 VCEACA1HC474M+ X 0.47 50V EL. AB
C505 VCEA0A1HW474M+ X 0.47 50V EL. AB
C506 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C507 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C510 RC-FZ0272CEZZ+ X 0.39 100V Mylar AB
C512 VCEA0A1EW476M+ X 47 25V EL. AB
C514 VCEA0A1VW107M+ X 100 35V EL. AB
C516 VCKYCY1HB472KY X 100 35V EL. AA
C517 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C518 VCQYTA2AA473J+ X 0.047 100V Mylar AB
C522 VCFYFA1HA334J+ X 0.33 50V Mylar AB
C523 VCEA0A1HW105M+ X 1 50V EL. AB
C601 VCEA0A1CW477M+ X 470 16V EL. AB
C602 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C603 VCEA0A1HW225M+ X 2.2 50V EL. AB
C604 VCKYCY1EB223KY X 0.022 25V Ceramic AA
C606 VCKYPA2HB561K+ X 560p 500V Ceramic AB
C607 VCKYPA1HB472K+ X 4700p 50V Ceramic AB
C608 RC-KZ0033CEZZ X 150p 2kV Ceramic AB
p
U
C609 VCFPVC3ZA143H X 14000p 1800V M.Poly. AB
C610 VCKYPH3DB561K X 560p 2kV Ceramic AB
C611 VCEA0A1EW477M+ X 470 25V EL. AB
C614 VCEA0A1EW108M+ X 1000 25V EL. AB
C615 VCFYSB2EB823J X 0.082 250V M.Poly.. AB
C616 VCKYPA2HB471K+ X 470p 500V Ceramic AB
C617 VCEA0A1HW474M+ X 0.47 50V EL. AB
C622 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C623 VCEA4A2EN106M+ X 10 250V EL. AB
C652 VCEA0A1HW476M+ X 47 50V EL. AB
C653 VCEA0A1HW106M+ X 10 50V EL. AB
C674 VCKYCY1HB391KY X 390p 50V Ceramic AA
C675 VCEA0A1HW106M+ X 10 50V EL. AB
C677 RC-FZ0377CEZZ X 4.7 50V Mylar AC
p
U
C678 VCQPCU2GA563J X 0.056 400V M.Poly.. AB
C681 VCFPFA2EB334J X 0.68 250V M.Poly. AB
C682 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C685 VCQYTA1HM333J+ X 0.033 50V Mylar AB
U
C701 RC-FZA022WJZZ X 0.22
AC250V M.Poly. AB
C702 RC-KZ0029CEZZ+ X 0.01
AC250V Ceramic AB
C703 RC-KZ0029CEZZ+ X 0.01
AC250V Ceramic AB
p
U
C705 RC-EZ0719CEZZ X 560 200V EL. AF
U
C706 RC-KZ0089GEZZA X 1000p
AC250V Ceramic AB
U
C707 RC-KZ0092GEZZA X 3300p
AC250V Ceramic AB
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
Ref. No. Part No. « Description Code
U
C723 RC-EZ0724CEZZ X 100 160V EL. AC
C725 RC-EZA064WJZZ X 220 160V EL. AD
C726 RC-KZ0226CEZZ+ X 560p 2kV Ceramic AB
C727 RC-KZ0226CEZZ+ X 560p 2kV Ceramic AB
C729 VCEA0A1HW106M+ X 10 50V EL. AB
C730 VCEA4A1VN108M+ X 1000 35V EL. AC
C731 RC-EZ0385CEZZ+ X 1000 16V EL. AB
C732 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C733 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C734 VCKYPA2HB471K+ X 470p 500V Ceramic AB
C735 VCKYPA2HB471K+ X 470p 500V Ceramic AB
C736 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C737 VCEA0A1HW226M+ X 22 50V EL. AB
C738 VCFPVC3CA102H X 1000p
1250V M.Poly. AB
C739 RC-EZ0385CEZZ+ X 1000 16V EL. AB
C740 VCEA0A1HW476M+ X 47 50V EL. AB
C741 VCEA4A2AN105M+ X 1 100V EL. AB
C742 VCEA0A1HW226M+ X 22 50V EL. AB
C743 RC-KZ0036CEZZ+ X 330p 2kV Ceramic AB
C744 VCKYPA2HB471K+ X 470p 500V Ceramic AB
C745 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C746 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C747 VCEA0A1HW475M+ X 4.7 50V EL. AB
C750 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C753 RC-KZ0036CEZZ+ X 330p 2kV Ceramic AB
C754 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C755 VCEA0A1EW476M+ X 47 25V EL. AB
C758 VCEA0A1HW475M+ X 4.7 50V EL. AB
C780 VCEA0A1HW226M+ X 22 50V EL. AB
C781 VCFYFA1HA105J+ X 1 50V M-Poly. AB
C782 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C783 VCQYTA1HM103J+ X 0.01 50V Mylar AB
C784 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C801 VCCCCY1HH110JY X 11p 50V Ceramic AA
C802 VCKYCY1HB222KY X 2200p 50V Ceramic AA
C803 VCEA0A1HW224M+ X 0.22 50V EL. AB
C804 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C805 VCEA0A0JW108M+ X 1000 6.3V EL. AB
C806 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C807 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C808 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C809 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C810 VCEA0A1CW477M+ X 470 16V EL. AB
C812 VCQYTA1HM104J+ X 0.1 50V Mylar AB
C901 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C902 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C903 VCKYCY1HB681KY X 680p 50V Ceramic AA
C904 VCEA0A1HW105M+ X 1 50V EL. AB
C905 VCEA0A1HW105M+ X 1 50V EL. AB
C906 VCKYCY1HB681KY X 680p 50V Ceramic AA
C907 VCEA0A1HW105M+ X 1 50V EL. AB
C908 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C909 VCEA0A1HW105M+ X 1 50V EL. AB
C910 VCEA0A1HW105M+ X 1 50V EL. AB
C911 VCEA0A1HW105M+ X 1 50V EL. AB
C912 VCEA0A1HW105M+ X 1 50V EL. AB
C913 VCEA0A1HW105M+ X 1 50V EL. AB
C914 VCKYCY1HB681KY X 680p 50V Ceramic AA
C915 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C916 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C917 VCEA0A1HW105M+ X 1 50V EL. AB
C918 VCKYCY1HB681KY X 680p 50V Ceramic AA
C919 VCEA0A1HW105M+ X 1 50V EL. AB
C920 VCEA0A1HW105M+ X 1 50V EL. AB
C921 VCKYCY1HB681KY X 680p 50V Ceramic AA
C922 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C923 VCEA0A1CW107M+ X 100 16V EL. AB
C926 VCEA0A1EW476M+ X 47 25V EL. AB
C928 VCEA0A1HW105M+ X 1 50V EL. AB
PWB-A: DUNTKC290WEA4
MAIN UNIT
27F543
