Ref. No. Part No. « Description Code
C930 VCEA0A1HW475M+ X 4.7 50V EL. AB
C931 VCKYCY1HB183KY X 0.018 50V Ceramic AA
C932 VCKYCY1HB183KY X 0.018 50V Ceramic AA
C933 VCEA0A1HW475M+ X 4.7 50V EL. AB
C934 VCEA0A1EW476M+ X 47 25V EL. AB
C935 VCEA0A1HW475M+ X 4.7 50V EL. AB
C936 VCEA0A1HW475M+ X 4.7 50V EL. AB
C937 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C953 VCKYCY1HB681KY X 680p 50V Ceramic AA
C956 VCEA0A1CW477M+ X 470 16V EL. AB
C962 VCCCCY1HH470JY X 47p 50V Ceramic AA
C1434 VCEA0A1EW476M+ X 47 25V EL. AB
C1437 VCEA0A1EW476M+ X 47 25V EL. AB
C2001 VCCCCY1HH101JY X 100p 50V Ceramic AA
C2002 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C2025 VCCCCY1HH101JY X 100p 50V Ceramic AA
C2040 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C2041 VCEA0A1HW105M+ X 1 50V EL. AB
C2043 VCCCCY1HH331JY X 330p 50V Ceramic AB
C2044 VCCCCY1HH100DY X 10p 50V Ceramic AA
C2046 VCEA0A1EW476M+ X 47 25V EL. AB
C2047 VCKYCY1CB473KY X 0.047 16V Ceramic AA
C2060 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C2061 VCCCCY1HH101JY X 100p 50V Ceramic AA
C2062 VCEA0A1CW107M+ X 100 16V EL. AB
C2063 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C2064 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C2201 VCKYCY1HB681KY X 680p 50V Ceramic AA
C2202 VCCCCY1HH330JY X 33p 50V Ceramic AA
C2601 VCEA0A1EW476M+ X 47 25V EL. AB
C2602 VCCCCY1HH101JY X 100p 50V Ceramic AA
C3001 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3002 VCKYCY1HB562KY X 5600p 50V Ceramic AA
C3003 VCKYCY1EB123KY X 0.012 25V Ceramic AA
C3004 VCEA0A1HW105M+ X 1 50V EL. AB
C3005 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3006 VCEA0A1HW106M+ X 10 50V EL. AB
C3007 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3008 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C3009 VCEA0A1CW477M+ X 470 16V EL. AB
C3010 VCE9GA1HW475M+ X 4.7 50V EL. AB
C3011 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3012 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3013 VCKYCY1HB272KY X 2700p 50V Ceramic AA
C3014 VCKYCY1CB473KY X 0.047 16V Ceramic AA
C3015 VCEACA1HC335K+ X 3.3 50V EL. AB
C3016 VCE9GA1HW475M+ X 4.7 50V EL. AB
C3017 VCEACA1CC106K+ X 10 16V EL. AB
C3018 VCEA0A1HW105M+ X 1 50V EL. AB
C3021 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3022 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3025 VCKYCY1CB473KY X 0.047 16V Ceramic AA
C3027 VCKYCY1CB473KY X 0.047 16V Ceramic AA
C3028 VCKYCY1HB682KY X 6800p 50V Ceramic AA
C3029 VCKYCY1HB682KY X 6800p 50V Ceramic AA
RJ1 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ7 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ8 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ9 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ10 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
PWB-A: DUNTKC290WEA4
MAIN UNIT
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No.
«
Description Code
RJ11 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ12 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ13 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ14 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ15 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ16 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ19 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ20 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ21 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ22 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ23 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ24 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ25 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ30 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ33 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ36 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ38 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ39 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ40 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ42 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ45 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ47 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ48 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ50 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R54 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R55 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R56 VRD-RA2BE823JY X 82k 1/8W Carbon AA
R57 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R201 VRS-CY1JF151JY X 150 1/16W M-Ox. AA
R202 VRS-CY1JF122JY X 1.2k 1/16W M-Ox. AA
R203 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R204 VRS-CY1JF270JY X 27 1/16W M-Ox. AA
R205 VRS-CY1JF331JY X 330 1/16W M-Ox. AA
R206 VRD-RA2BE101JY X 100 1/8W Carbon AA
R211 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R212 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R225 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R226 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R227 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R232 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R234 VRD-RA2BE271JY X 270 1/8W Carbon AA
R236 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R301 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R305 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R306 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R307 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R308 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R355 VRD-RA2BE821JY X 820 1/8W Carbon AA
R361 VRD-RA2BE224JY X 220k 1/8W M-Ox. AA
R362 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R363 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R364 VRD-RA2BE152JY X 1.5k 1/8W Carbon AA
R365 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
U
R367 VRN-RL3DB1R2J+ X 1.2 2W M-Film AB
R368 VRD-RA2BE222JY X 2.2k 1/8W Carbon AA
R369 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R371 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R372 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R403 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R404 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R406 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R407 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R408 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R410 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R411 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R412 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R413 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R422 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R430 VRS-CY1JF391JY X 390 1/16W M-Ox. AA
27F543
28
