Ref. No. Part No. « Description Code
R431 VRS-CY1JF331JY X 330 1/16W M-Ox. AA
R432 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R436 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R437 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R438 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R439 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R441 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R442 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R444 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R445 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R446 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R447 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R448 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R449 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R450 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R451 VRS-RG3AB103J+ X 10k 1W M-Ox. AB
R452 VRD-RM2HD393JY X 39k 1/2W Carbon AA
R453 VRD-RM2HD333JY X 33k 1/2W Carbon AA
R454 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R456 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R460 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R461 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R462 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R463 VRD-RA2EE680JY X 68 1/4W Carbon AA
R464 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R467 VRS-CY1JF123JY X 12k 1/16W M-Ox. AA
R471 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R472 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R473 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R474 VRS-CY1JF681JY X 680 1/16W M-Ox. AA
R475 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R476 VRS-CY1JF393JY X 39k 1/16W M-Ox. AA
R477 VRS-CY1JF182JY X 1.8k 1/16W M-Ox. AA
R478 VRS-CY1JF151JY X 150 1/16W M-Ox. AA
R479 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R480 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R481 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R482 VRS-CY1JF100JY X 10 1/16W M-Ox. AA
R483 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
U
R501 VRN-RL3ABR47J+ X 0.47 1W M-Film AB
R502 VRN-RA2BK822FY X 8.2k 1/8W M-Film AB
R503 VRS-CY1JF105JY X 1M 1/16W M-Ox. AA
R504 VRS-CY1JF154JY X 150k 1/16W M-Ox. AA
R505 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R510 VRN-RA2BK103FY X 10k 1/8W M-Film AB
R511 VRN-RA2BK222FY X 2.2k 1/8W M-Film AB
R512 VRN-RA2BK272FY X 2.7k 1/8W M-Film AB
R513 VRD-RM2HD1R0JY X 1 1/2W Carbon AA
R517 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R518 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R521 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
U
R523 VRN-RL3DB1R0J+ X 1 2W M-Film AB
U
R524 VRS-RG3AB391J+ X 390 1W M-Ox. AB
R601 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R603 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
U
R604 VRS-KA3NG562J X 5.6k 7.0W M-Ox. AB
R605 VRD-RM2HD331JY X 330 1/2W Carbon AA
R606 VRD-RM2HD331JY X 330 1/2W Carbon AA
U
R609 VRS-RG3AB562J+ X 5.6k 1W M-Ox. AB
R610 VRD-RM2HD220JY X 22 1/2W Carbon AA
R612 VRS-CY1JF154JY X 150k 1/16W M-Ox. AA
R613 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
PWB-A: DUNTKC290WEA4
MAIN UNIT
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No.
«
Description Code
R614 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
U
R615 VRS-KA3NG3R3K X 3.3 7.0W M-Ox. AB
R618 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
U
R621 VRN-RL3DB1R5J+ X 1.5 2W M-Film AB
U
R623 VRN-RL3AB4R7J+ X 4.7 1W M-Film AB
U
R624 VRS-RG3DB332J+ X 3.3k 2W M-Ox. AB
R625 VRD-RA2BE102JY X 1k 1/8W Carbon AA
U
R627 VRN-RL3ABR47J+ X 0.47 1W M-Film AB
U
R628 VRN-RL3ABR47J+ X 0.47 1W M-Film AB
p
U
R651 VRS-RG2HC270J+ X 27 1/2W M-Ox. AB
R652 VRD-RA2EE103GY X 10k 1/4W Carbon AA
R653 VRD-RA2EE562GY X 5.6k 1/4W Carbon AA
U
R658 VRS-RG3DB183J+ X 18k 2W M-Ox. AB
R663 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R670 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R684 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
R685 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R686 VRD-RA2EE332JY X 3.3k 1/4W Carbon AA
R687 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R688 VRN-RL3DB3R3J+ X 3.3 2W M-Film AB
R689 VRD-RM2HD824JY X 820k 1/2W Carbon AA
R690 VRS-RG3LB471J+ X 470 3.0W M-Ox. AB
R691 VRS-CY1JF394JY X 390k 1/16W M-Ox. AA
R692 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R693 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R694 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R695 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R696 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R697 VRS-CY1JF684JY X 680k 1/16W M-Ox. AA
R698 VRS-CY1JF475JY X 4.7M 1/16W M-Ox. AA
U
R701 RR-DZ0049CEZZY X 3.9M 1/2W Solid AB
U
R703 VRW-KQ4AC1R2K X 1.2 10W Cement AB
U
R705 VRN-RL3DBR18J+ X 0.18 2W M-Film AB
U
R706 VRN-RL3DBR18J+ X 0.18 2W M-Film AB
R707 VRD-RM2HD270JY X 27 1/2W Carbon AA
R708 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R709 VRS-CY1JF393JY X 39k 1/16W M-Ox. AA
U
R710 VRS-RG2HC103J+ X 10k 1/2W M-Ox. AB
R711 VRS-CY1JF334JY X 330k 1/16W M-Ox. AA
R712 VRD-RM2HD100JY X 10 1/2W Carbon AA
U
R713 VRS-RG2HC152J+ X 1.5k 1/2W M-Ox. AB
R714 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R715 VRN-RL2HCR56J+ X 0.56 1/2W M-Film AB
R716 VRD-RM2HD100JY X 10 1/2W Carbon AA
R720 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R724 VRD-RM2HD101JY X 100 1/2W Carbon AA
R725 VRD-RM2HD821JY X 820 1/2W Carbon AA
R734 VRD-RM2HD124JY X 120k 1/2W Carbon AA
U
R737 VRN-RL3LBR82J+ X 0.82 3.0W M-Film AB
R742 VRD-RA2BE222JY X 2.2k 1/8W Carbon AA
R743 VRD-RM2HD470JY X 47 1/2W Carbon AA
R744 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R745 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R750 VRS-CY1JF224JY X 220k 1/16W M-Ox. AA
R751 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R752 VRD-RA2BE392JY X 3.9k 1/8W Carbon AA
R753 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R754 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R755 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R756 VRD-RA2BE152JY X 1.5k 1/8W Carbon AA
U
R757 VRN-RL3DB4R7J+ X 4.7 2W M-Film AB
R759 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R761 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R762 VRD-RA2EE151JY X 150 1/4W Carbon AA
R764 VRD-RM2HD562JY X 5.6k 1/2W Carbon AA
R767 VRD-RM2HD151JY X 150 1/2W Carbon AA
R768 VRD-RA2BE393JY X 39k 1/8W Carbon AA
R775 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R776 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
27F543
29
