Ref. No. Part No. « Description Code
R801 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R802 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R803 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R805 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R806 VRS-CY1JF681JY X 680 1/16W M-Ox. AA
R807 VRS-CY1JF681JY X 680 1/16W M-Ox. AA
R808 VRS-CY1JF681JY X 680 1/16W M-Ox. AA
R810 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R903 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R904 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R905 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R906 VRD-RA2BE332JY X 3.3k 1/8W Carbon AA
R907 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R908 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R910 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R911 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R912 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R913 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R914 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R915 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R916 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R917 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R918 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R922 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R923 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R924 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R925 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R926 VRS-CY1JF680JY X 68 1/16W M-Ox. AA
R927 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R929 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R930 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R931 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R932 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R933 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R934 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R935 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R936 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R937 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R938 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R939 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R940 VRS-CY1JF8R2JY X 8.2 1/16W M-Ox. AA
R941 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R942 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R943 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R944 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R945 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R946 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R947 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R948 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R949 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R950 VRS-CY1JF560JY X 56 1/16W M-Ox. AA
R951 VRD-RA2BE680JY X 68 1/8W Carbon AA
R952 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R953 VRS-CY1JF220JY X 22 1/16W M-Ox. AA
R954 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R955 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R957 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R958 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R959 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R960 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R961 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R962 VRS-CY1JF332FY X 3.3k 1/16W M-Ox. AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
PWB-A: DUNTKC290WEA4
MAIN UNIT
Ref. No. Part No.
«
Description Code
R963 VRD-RA2BE101JY X 100 1/8W Carbon AA
R964 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R967 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R968 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R969 VRS-CY1JF472FY X 4.7k 1/16W M-Ox. AA
R970 VRD-RA2BE6R8JY X 6.8 1/8W Carbon AA
R971 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R972 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R973 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R974 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R975 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R982 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R983 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R984 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
U
R1420 VRN-RL3LB2R7J+ X 2.7 3.0W M-Film AB
R2001 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R2004 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2008 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R2010 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R2013 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R2021 VRS-CY1JF334JY X 330k 1/16W M-Ox. AA
R2024 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R2025 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R2026 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R2027 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R2028 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R2031 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R2033 VRS-CY1JF334JY X 330k 1/16W M-Ox. AA
R2040 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R2041 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R2042 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2043 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R2044 VRS-CY1JF153JY X 15k 1/16W M-Ox. AA
R2045 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R2046 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2047 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R2048 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R2051 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R2054 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R2060 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R2061 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R2062 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R2063 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R2064 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R2073 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2084 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2086 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2088 VRS-CY1JF224JY X 220k 1/16W M-Ox. AA
R2089 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R2090 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R2092 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2093 VRS-CY1JF224JY X 220k 1/16W M-Ox. AA
R2094 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R2095 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2096 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2101 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2102 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2201 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R2202 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2203 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R2211 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R2212 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R2213 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R2401 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2402 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2403 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2404 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2501 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R2502 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
27F543
30
