Ref. No. Part No. « Description Code
R2503 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2504 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2505 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R2506 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R2507 VRD-RA2BE183JY X 18k 1/8W Carbon AA
R2508 VRD-RA2BE183JY X 18k 1/8W Carbon AA
R2509 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2601 VRD-RA2BE100JY X 10 1/8W Carbon AA
R2603 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2605 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2606 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3001 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R3002 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R3003 VRS-CY1JF105JY X 1M 1/16W M-Ox. AA
R3004 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R3005 VRS-CY1JF623JY X 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302JY X 3k 1/16W M-Ox. AA
R3010 VRS-CY1JF392JY X 3.9k 1/16W M-Ox. AA
R3017 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3018 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3019 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R3024 VRD-RA2BE102JY X 1k 1/8W Carbon AA
S2501 QSW-KA003WJZZ+ X Switch
, AB
S2502 QSW-KA003WJZZ+ X Switch, AB
S2503 QSW-KA003WJZZ+ X Switch, AB
S2504 QSW-KA003WJZZ+ X Switch, AB
S2505 QSW-KA003WJZZ+ X Switch, AB
S2506 QSW-KA003WJZZ+ X Switch, AB
FB601 RBLN-0047CEZZY X FERRITE BEAD AB
FB706 RBLN-0037CEZZY X FERRITE BEAD AB
FB2001 RBLN-0037CEZZY X FERRITE BEAD AB
U
ACC701 QACCDA012WJPZ X AC Cord AE
U
F701 QFS-B4023CEZZ X FUSE - 4A 125V AB
FH701 QFSHD1013CEZZ+ X FUSE CLIP AB
FH702 QFSHD1014CEZZ+ X FUSE CLIP AB
J904 QJAKGA023WJZZ X JACK (A/V) AC
J921 QSOCD0456CEZZ X Socket, S-Video AC
J1401 QTANJ1101SEZZ X AV In/Out Terminal AF
P361 QPLGN0461CEZZA X Plug, 4pin(S1-4) AB
P401 QPLGN0861CEZZA X Plug, 8pin(CJ) AB
P605 QPLGN0160FJZZ X Plug, 5pin(K1-5) AB
P621 QPLGN0761CEZZA X Plug, 7pin(N) AB
P651 QPLGN0361CEZZA X Plug, 3pin (TP651-3) AB
P702 QPLGN0269GEZZ X Plug, 2pin (P1-2) AB
P703 QPLGN0260CEZZ X Plug, 2pin (M1-2) AB
P2401 QPLGN0661CEZZA X Plug, 6pin AB
CF2040 RCRM-0003CEZZ+ X Ceramic Vibrator AC
RDA361 PRDAR0258PEFW X Heat Sink for IC361 AC
RDA501 PRDARA039WJFW X Heat Sink for IC501 AD
RDA601 PRDARA041WJFW X Heat Sink for Q602 AD
RDA671 PRDARA057WJFW X Heat Sink for Q673 AC
RDA701 PRDAR0279PEFW X Heat Sink for Q701 AB
RDA750 PRDAR5072CEFW X Heat Sink for IC1401 AB
RDA1403 PRDAR5072CEFW X Heat Sink for IC1403 AB
RMC2601RRMCU0222CEZZ X R/C RECEIVER AD
U
RY701 RRLYJ0081CEZZ X Relay AD
RY702 RRLYJ0088CEZZ X Relay AC
PWB-A: DUNTKC290WEA4
MAIN UNIT
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No. « Description Code
U
IC850 VHITDA6103Q-1 X TDA6103Q/N3 AG
Q850 VS2SA1266-Y-1+ X 2SA1266(Y) AB
Q851 VS2SC3198-G-1+ X 2SC3198-G AB
Q1504 VS2SC3198-G-1+ X 2SC3198-G AB
Q1505 VS2SA1266-Y-1+ X 2SA1266(Y) AB
Q1506 VS2SA1964E/-1 X 2SA1964E AC
Q1507 VS2SC5248E/-1 X 2SC5248E AC
D850 RH-DX0220CEZZY X DX0220CE AB
D851 RH-DX0220CEZZY X DX0220CE AB
D852 RH-DX0220CEZZY X DX0220CE AB
D853 RH-EX0647GEZZY X Zener Diode, 15V AB
D854 VHD1SS119//-1Y X Diode AA
D855 VHD1SS119//-1Y X Diode AA
D862 VHD1SS119//-1Y X Diode AA
D1502 VHD1SS119//-1Y X Diode AA
D1503 VHD1SS119//-1Y X Diode AA
D1506 RH-DX0487CEZZY X Diode AB
D1507 RH-DX0487CEZZY X Diode AB
D1510 VHD1SS119//-1Y X Diode AA
C850 VCFYSB2EB224K X 0.22 250V M.Poly. AB
C851 RC-KZ018JCEZZ X 0.01 AC250V Ceramic AB
C852 VCEA0A1CW107M+ X 100 16V EL. AB
C853 VCFYFA1HA224J+ X 0.22 50V Mylar AB
C854 VCEA0A1CW227M+ X 220 16V EL. AB
C855 VCEA0A2EW106M+ X 10 250V EL. AB
C856 VCEA0A1HW226M+ X 22 50V EL. AB
C1501 VCEA0A1CW476M+ X 47 16V EL. AB
C1506 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1508 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C1509 VCKYPA1HB472K+ X 4700p 50V Ceramic AB
C1510 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1511 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1515 VCEA0A1HW476M+ X 47 50V EL. AB
C1516 VCEA0A1HW476M+ X 47 50V EL. AB
C1517 VCEA0A2AW106M+ X 10 100V EL. AB
C1518 VCCSPA2HL560K+ X 56p 500V Ceramic AB
C1519 VCEA0A2CW106M+ X 10 160V EL. AB
U
R850 VRS-SV2HC152J X 1.5k 1/2W M-Ox. AB
U
R851 VRS-SV2HC152J X 1.5k 1/2W M-Ox. AB
U
R852 VRS-SV2HC152J X 1.5k 1/2W M-Ox. AB
U
R853 VRS-SV2HC272J X 2.7k 1/2W M-Ox. AB
U
R854 VRS-SV2HC272J X 2.7k 1/2W M-Ox. AB
U
R855 VRS-SV2HC272J X 2.7k 1/2W M-Ox. AB
U
R856 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R857 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R858 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R861 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R862 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
R863 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
R864 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
U
R867 VRS-SV2HC392J X 3.9k 1/2W M-Ox. AB
U
R868 VRS-SV2HC682J X 6.8k 1/2W M-Ox. AB
R869 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R870 VRD-RA2BE223JY X 22k 1/8W Carbon AA
PWB-A: DUNTKA527WEW7
CRT Unit
Switch
FERRITE BEAD
MISCELLANEOUS PARTS
INTEGRATED CIRCUIT
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
TRANSISTORS
DIODES
27F543
31
