Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
- 48 -
27J-S100/S180/260
CJ27S10/S26
R2061 VRS-CY1JF562J J 5.6k 1/16W M.Oxide AA
R2062 VRD-RA2BE183J J 18k 1/8W Carbon AA
R2063 VRS-CY1JF222J J 2.2k 1/16W M.Oxide AA
R2064 VRS-CY1JF332J J 3.3k 1/16W M.Oxide AA
R2065 VRS-CY1JF102J J 1k 1/16W M.Oxide AA
R2068 VRS-CY1JF103J J 10k 1/16W M.Oxide AA
R2070 VRS-CY1JF103J J 10k 1/16W M.Oxide AA
R2071 VRS-CY1JF102J J 1k 1/16W M.Oxide AA
R2072 VRS-CY1JF102J J 1k 1/16W M.Oxide AA
R2101 VRS-CY1JF101J J 100 1/16W M.Oxide AA
R2102 VRS-CY1JF101J J 100 1/16W M.Oxide AA
R2201 VRS-CY1JF222J J 2.2k 1/16W M.Oxide AA
R2202 VRS-CY1JF103J J 10k 1/16W M.Oxide AA
R2203 VRD-RA2BE184J J 180k 1/8W Carbon AA
R2211 VRS-CY1JF222J J 2.2k 1/16W M.Oxide AA
R2212 VRS-CY1JF682J J 6.8k 1/16W M.Oxide AA
R2213 VRS-CY1JF333J J 33k 1/16W M.Oxide AA
R2401 VRS-CY1JF101J J 100 1/16W M.Oxide AA
R2402 VRS-CY1JF101J J 100 1/16W M.Oxide AA
R2403 VRS-CY1JF101J J 100 1/16W M.Oxide AA
R2404 VRS-CY1JF101J J 100 1/16W M.Oxide AA
R2501 VRD-MN2BE103J J 10k 1/8W Carbon AA
R2503 VRD-MN2BE273J J 27k 1/8W Carbon AA
R2504 VRD-MN2BE123J J 12k 1/8W Carbon AA
R2505 VRD-MN2BE563J J 56k 1/8W Carbon AA
R2506 VRD-MN2BE563J J 56k 1/8W Carbon AA
R2507 VRD-MN2BE823J J 82k 1/8W Carbon AA
R2508 VRD-MN2BE153J J 15k 1/8W Carbon AA
R2509 VRD-MN2BE272J J 2.7k 1/8W Carbon AA
R2601 VRD-RA2BE331J J 330 1/8W Carbon AA
R3001 VRS-CY1JF221J J 220 1/16W M.Oxide AA
R3002 VRS-CY1JF221J J 220 1/16W M.Oxide AA
R3003 VRS-CY1JF105J J 1M 1/16W M.Oxide AA
R3004 VRS-CY1JF104J J 100k 1/16W M.Oxide AA
R3005 VRS-CY1JF623J J 62k 1/16W M.Oxide AA
R3007 VRS-CY1JF332J J 3.3k 1/16W M.Oxide AA
R3008 VRS-CY1JF302J J 3k 1/16W M.Oxide AA
R3010 VRS-CY1JF392J J 3.9k 1/16W M.Oxide AA
R3011 VRS-CY1JF102J J 1k 1/16W M.Oxide AA
R3012 VRS-CY1JF102J J 1k 1/16W M.Oxide AA
R3013 VRS-CY1JF104J J 100k 1/16W M.Oxide AA
R3014 VRS-CY1JF104J J 100k 1/16W M.Oxide AA
R3016 VRD-MN2BE750J J 75 1/8W Carbon AA
R3017 VRD-RA2BE102J J 1k 1/8W Carbon AA
R3018 VRD-RA2BE102J J 1k 1/8W Carbon AA
SWITCHES
S501 QSW-B0015CEZZ J V-Lin. AC
DUNTK9254WEK5/K6/K4
27J-S100/180/CJ27S10 MAIN UNIT
S2501 QSW-K0079GEZZ J Power AB
S2502 QSW-K0079GEZZ J Vol-down AB
S2503 QSW-K0079GEZZ J Vol-up AB
S2504 QSW-K0079GEZZ J CH-down AB
S2505 QSW-K0079GEZZ J CH-up AB
MISCELLANEOUS PARTS
å RY701 RRLYU0036CEZZ J Relay AM
or RRLYU0028CEZZ AK
or RRLYU0038CEZZ
å F701 QFS-B4023CEZZ J Fuse AC
or QFS-B4021GEZZ
FB601 RBLN-0037CEZZ J Balun AB
FB701 RBLN-0037CEZZ J Balun AB
FB702 RBLN-0037CEZZ J Balun AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
P52 QPLGN0160CEZZ J Plug AB
P351 QPLGN0461CEZZ J Plug AB
P401 QPLGN0561CEZZ J Plug AB
P602 QPLGN0160FJZZ J Plug AD
P651 QPLGN0361CEZZ J Plug AB
P701 QPLGN0207CEZZ J Plug AA
P702 QPLGN0461CEZZ J Plug AB
P703 QPLGN0269GEZZ J Plug AB
P707 QPLGN0160CEZZ J Plug AB
P901 QPLGN0561CEZZ J Plug AB
P2401 QPLGN0561CEZZ J Plug AB
RMC2601 RRMCU0224CEZZJ Remote Receiver AM
or RRMCU0216CEZZ J Remote Receiver AM
RDA501 PRDAR0234PEFW M Heat Sink AE
RDA604 PRDAR0233PEFW M Heat Sink AE
RDA707 PRDAR0026PEFW R Heat Sink AD
RDA708 PRDAR0026PEFW R Heat Sink AD
RDA751 PRDAR5072CEFW J Heat Sink AC
TAN921 QTANJ0323CEZZ M V/A Terminal AF
LX-BZ3049GEFD J Screw AA
