Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
- 49 -
27J-S100/S180/260
CJ27S10/S26
TUNER
å TU51 VTU115B8025AT M Tuner BA
INTEGRATED CIRCUITS
IC101 VHiKA78S05P-1 J KiA78S05P AD
åçIC201 RH-iX2701CEN1 R I C AY
IC351 VHiTDA7233/-1 J TDA7233 AF
IC352 VHiTDA7233/-1 J TdA7233 AF
IC421 VHiTA7347P/-1 M TA7347P AG
å IC501 VHiTA8427K/-1 J TA8427k AL
åçIC701 RH-iX0758CEZZ J T8150 AF
IC702 VHiT8889A//-1 J T8889A AL
IC751 VHiKA7809Pi-1 M KiA7809Pi AE
IC821 VHiTA7347P/-1 M TA7347P AG
IC951 VHiLA7956//-1 J LA7956 AG
IC2001 RH-iX2947CEZZ M I C AT
IC2040 VHiKiA7045P-1 J KiA7045P AD
or VHiPST994C/-1 AD
IC2101 RH-iX2447CEN1 J ST24C01B6 AL
IC3001 VHiCXA2053Q-1 M CXA2053Q/-T6 AS
TRANSISTORS
You can substitute "VS2SD601AR/-1 "for "VS2SC2462-C-1.
Q201 VS2SC2735//1E J 2SC2735 AC
Q301 VS2SD601AR/-1 R 2SD601(AR) AC
Q351 VS2SD601AR/-1 R 2SD601(AR) AC
Q352 VS2SD601AR/-1 R 2SD601(AR) AC
Q401 VS2SD601AR/-1 R 2SD601(AR) AC
Q402 VS2SB709AR/-1 J 2SB709(AR) AC
or VS2SA812-M51E J 2SA812 AC
Q403 VS2SD601AR/-1 R 2SD601(AR) AC
Q421 VS2SB709AR/-1 J 2SB709(AR) AC
or VS2SA812-M51E J 2SA812 AC
Q451 VS2SD601AR/-1 R 2SD601(AR) AC
Q601 VS2SC2655Y/-1 J 2SC2655(Y) AE
å Q602 VS2SD1556//1E J 2SD1556 AP
Q606 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q751 VS2SC1983//-2 J 2SC1983 AF
å Q752 VS2SC3198-Y-1 J 2SC3198 AA
Q753 VS2SA1013//1E J 2SA1013 AD
Q754 VS2SD601AR/-1 R 2SD601(AR) AC
Q821 VS2SD601AR/-1 R 2SD601(AR) AC
Q822 VS2SD601AR/-1 R 2SD601(AR) AC
Q921 VS2SD601AR/-1 R 2SD601(AR) AC
Q922 VS2SD601AR/-1 R 2SD601(AR) AC
Q923 VS2SD601AR/-1 R 2SD601(AR) AC
Q924 VS2SD601AR/-1 R 2SD601(AR) AC
Q2060 VS2SD601AR/-1 R 2SD601(AR) AC
Q2201 VS2SD601AR/-1 R 2SD601(AR) AC
Q2211 VS2SD601AR/-1 R 2SD601(AR) AC
Q2250 VS2SD601AR/-1 R 2SD601(AR) AC
DIODES
D51 RH-EX0293CEZZ J Zener Diode,5 1V AA
D52 RH-EX0701GEZZ J Zener Diode AB
D103 VHD1SS119//-1 J 1SS119 AB
D401 VHD1SS119//-1 J 1SS119 AB
D402 RH-EX0092CEZZ J Zener Diode,3 9V AB
D421 RH-EX0296CEZZ J Zener Diode AB
D451 VHD1SS119//-1 J Diode AB
D452 RH-EX0217CEZZ J Zener Diode,15V AB
D453 RH-EX0217CEZZ J Zener Diode,15V AB
D454 RH-EX0293CEZZ J Zener Diode,5 1V AA
D455 VHD1SS119//-1 J Diode AB
D456 VHD1SS119//-1 J Diode AB
D457 RH-EX0313CEZZ J Zener Diode AA
D501 RH-DX0441CEZZ J Diode AC
å D502 RH-DX0131CEZZ J Diode AC
D503 RH-DX0441CEZZ J Diode AC
D631 RH-EX0312CEZZ J Zener Diode AA
åçD651 RH-DX0131CEZZ J Diode AC
åçD652 RH-EX0655CEZZ J Zener Diode AE
åçD653 VHD1SS119//-1 J 1SS119 AB
åçD654 VHD1SS119//-1 J 1SS119 AB
å D701 RH-DX0154CEZZ J Diode AC
å D702 RH-DX0154CEZZ J Diode AC
å D703 RH-DX0154CEZZ J Diode AC
å D704 RH-DX0154CEZZ J Diode AC
å D705 VHD1SS119//-1 J Diode AB
å D706 RH-EX0238CEZZ J Zener Diode,75V AC
åçD707 VHSS6785GLB2E J Si Control Rectifier AL
åçD708 VHSS6785GLB2E J Si Control Rectifier AL
å D709 RH-DX0131CEZZ J Diode AC
å D710 RH-DX0131CEZZ J Diode AC
å D711 RH-DX0444CEZZ J Diode AH
å D751 RH-DX0441CEZZ J Diode AC
å D752 RH-EX0019TAZZ J Zener Diode AB
å D753 RH-DX0441CEZZ J Diode AC
å D754 RH-DX0441CEZZ J Diode AC
å D755 RH-DX0441CEZZ J Diode AC
å D756 RH-DX0441CEZZ J Diode AC
D757 VHD1SS119//-1 J Diode AB
D758 RH-DX0441CEZZ J Diode AC
D760 RH-DX0441CEZZ J Diode AC
D761 RH-DX0441CEZZ J Diode AC
D921 RH-EX0313CEZZ J Zener Diode AA
D922 RH-EX0313CEZZ J Zener Diode AA
PACKAGED CIRCUITS
å PR701 RMPTP0026CEZZ J Packaged Circuit AF
X801 RCRSB0001PEZZ R Crystal AL
FILTERS
CF301 RFiLC0029TAZZ J Filter AD
CF302 RFiLC0267CEZZ J Filter AD
CF401 RFiLC0013CEZZ J Filter AE
CF631 RFiLA0034CEZZ J Filter AD
CF2040 RFiLC0121GEZZ J Filter AD
DUNTK9254WEK8/K7
27J-S260/CJ27S26 MAIN UNIT
