Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
- 55 -
27J-S100/S180/260
CJ27S10/S26
SWITCHES
S501 QSW-B0015CEZZ J V-Lin AC
S2501 QSW-K0079GEZZ J Power AB
S2502 QSW-K0079GEZZ J V0l-down AB
S2503 QSW-K0079GEZZ J Vol-up AB
S2504 QSW-K0079GEZZ J CH-down AB
S2505 QSW-K0079GEZZ J CH-up AB
MISCELLANEOUS PARTS
å RY701 RRLYU0036CEZZ J Relay AM
or RRLYU0028CEZZ AK
å F701 QFS-B4023CEZZ J Fuse AC
or QFS-B4021GEZZ AE
FB601 RBLN-0037CEZZ J Balun AB
FB701 RBLN-0037CEZZ J Balun AB
FB702 RBLN-0037CEZZ J Balun AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
J921 QSOCD0427CEZZ J Socket AL
P52 QPLGN0160CEZZ J Plug AB
P351 QPLGN0461CEZZ J Plug AB
P401 QPLGN0561CEZZ J Plug AB
P602 QPLGN0160FJZZ J Plug AD
P651 QPLGN0361CEZZ J Plug AB
P701 QPLGN0207CEZZ J Plug AA
P702 QPLGN0461CEZZ J Plug AB
P703 QPLGN0269GEZZ J Plug AB
P707 QPLGN0160CEZZ J Plug AB
P901 QPLGN0561CEZZ J Plug AB
P1701 QPLGZ0810CEZZ J Plug AD
P1702 QPLGZ0610CEZZ J Plug AB
P1703 QPLGZ0810CEZZ J Plug AD
P2401 QPLGN0561CEZZ J Plug AB
RMC2601 RRMCU0224CEZZ J Remote Receiver AM
or RRMCU0216CEZZ J Remote Receiver AM
RDA501 PRDAR0234PEFW M Heat Sink AE
RDA604 PRDAR0233PEFW M Heat Sink AE
RDA707 PRDAR0026PEFW R Heat Sink AD
RDA708 PRDAR0026PEFW R Heat Sink AD
RDA751 PRDAR5072CEFW J Heat Sink AC
RDA752 PRDAR5072CEFW J Heat Sink AC
SLD1801 PSLDM0012MEFW M Shiele AA
TAN921 QTANJ0323CEZZ M A/V Terminal AF
LX-BZ3049GEFE J Screw AA
DUNTK9254WEK8/K7
27J-S260/CJ27S26 MAIN UNIT
DUNTK9310WEK1
FRONT AV UNIT
J1001 QJAKE0053GEZZ J Jack,Video in AD
J1002 QJAKE0055GEZZ J Jack, Audio in (L) AD
J1003 QJAKE0059GEZZ J Jack, Audio in (R) AC
P1001 QPLGN0541CEZZ J Plug AB
DUNTK8604WEK8/K9
CRT UNIT
TRANSISTORS
Q851 VS2SC3198-Y-1 J 2SC3198 AA
Q852 VS2SC3619LB1E J 2SC3619 AD
Q853 VS2SC3198-Y-1 J 2SC3198 AA
Q854 VS2SC3619LB1E J 2SC3619 AD
Q855 VS2SC3198-Y-1 J 2SC3198 AA
Q856 VS2SC3619LB1E J 2SC3619 AD
Q881 VS2SA1266-Y-1 J 2SA1266 AA
DIODES AND COIL
D881 VHD1SS119//-1 J 1SS119 AB
D882 VHD1SS119//-1 J 1SS119 AB
D884 VHD1SS119//-1 J 1SS119 AB
L851 VP-MK820K0000 J Peaking 82µH AB
CAPACITORS
C851 VCCSPA1HL391J J 390p 50V Ceramic AA
C852 VCCSPA1HL391J J 390p 50V Ceramic AA
C853 VCCSPA1HL391J J 390p 50V Ceramic AA
C854 RC-KZ0024CEZZ J 0.001 2kV Ceramic AC
or VCKYPB3DE472Z J 0.0047 2kV Ceramic AC
C883 VCEAGA1HW106M J 10 50V EL. AC
RESISTORS
R851 VRD-RA2BE470J J 47 1/8W Carbon AA
R852 VRD-RA2BE181J J 180 1/8W Carbon AA
R853 VRD-RA2BE121J J 120 1/8W Carbon AA
R855 VRD-RA2BE471J J 470 1/8W Carbon AA
R856 VRD-RA2BE221J J 220 1/8W Carbon AA
å R857 VRS-VV3LB123J J 12k 3.0W Metal.Oxide AB
R858 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R859 VRD-RA2BE470J J 47 1/8W Carbon AA
R860 VRD-RA2BE181J J 180 1/8W Carbon AA
R861 VRD-RA2BE121J J 120 1/8W Carbon AA
R863 VRD-RA2BE471J J 470 1/8W Carbon AA
R864 VRD-RA2BE221J J 220 1/8W Carbon AA
å R865 VRS-VV3LB123J J 12k 3.0W Metal.Oxide AB
R866 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R867 VRD-RA2BE470J J 47 1/8W Carbon AA
R868 VRD-RA2BE181J J 180 1/8W Carbon AA
R869 VRD-RA2BE121J J 120 1/8W Carbon AA
R871 VRD-RA2BE471J J 470 1/8W Carbon AA
R872 VRD-RA2BE221J J 220 1/8W Carbon AA
å R873 VRS-VV3LB123J J 12k 3.0W Metal.Oxide AB
R874 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R881 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R882 VRD-RA2BE271J J 270 1/8W Carbon AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R895 VRD-RA2BE470J J 47 1/8W Carbon AA
