PWB-A: DUNTKD571WEA6
MAIN UNIT
Ref. No. Part No.  Description Code
R2501 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R2502 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R2503 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2504 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2505 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R2506 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R2507 VRD-RA2BE183JY X 18k 1/8W Carbon AA
R2508 VRD-RA2BE183JY X 18k 1/8W Carbon AA
R2509 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2601 VRD-RA2BE100JY X 10 1/8W Carbon AA
R2603 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2605 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2606 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3001 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R3002 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R3003 VRS-CY1JF105JY X 1M 1/16W M-Ox. AA
R3004 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R3005 VRS-CY1JF623JY X 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302JY X 3k 1/16W M-Ox. AA
R3010 VRS-CY1JF392JY X 3.9k 1/16W M-Ox. AA
R3011 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3012 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3017 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3018 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3024 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R3027 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3029 VRS-CY1JF153JY X 15k 1/16W M-Ox. AA
R3030 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R3031 VRS-CY1JF474JY X 470k 1/16W M-Ox. AA
R3032 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3033 VRS-CY1JF474JY X 470k 1/16W M-Ox. AA
R3034 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3035 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3036 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3037 VRS-CY1JF153JY X 15k 1/16W M-Ox. AA
R3038 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R3039 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
S2501 QSW-K0003AJZZ+ X Switch, POWER AB
S2502 QSW-K0003AJZZ+ X Switch, MENU AB
S2503 QSW-K0003AJZZ+ X Switch, VOL.-DOWN AB
S2504 QSW-K0003AJZZ+ X Switch, VOL.-UP AB
S2505 QSW-K0003AJZZ+ X Switch, CH-DOWN AB
S2506 QSW-K0003AJZZ+ X Switch, CH-UP AB
FB601 RBLN-0047CEZZY X Ferrite Bead AB
FB706 RBLN-0037CEZZY X Ferrite Bead AA
FB707 RBLN-0020CEZZ+ X Ferrite Bead AB
FB1103 RBLN-0210TAZZY X Ferrite Bead AB
FB1104 RBLN-0210TAZZY X Ferrite Bead AB
FB2001 RBLN-0037CEZZY X Ferrite Bead AA
ACC701 QACCDA012WJPZ X AC Cord AH
F701 QFS-B4023CEZZ X FUSE - 4A 125V AC
FH701 QFSHD1013CEZZ+ X FUSE CLIP AA
FH702 QFSHD1014CEZZ+ X FUSE CLIP AA
J904 QJAKGA033WJZZ X Jack, Front AV IN JACK AE
J921 QSOCD0456CEZZ X Socket, S-Video AD
J1401 QTANJ1101SEZZ X AV In/Out Terminal AH
P361 QPLGN0461CEZZA X plug,4pin AB
P402 QPLGN0661CEZZA X plug,6pin AB
P605 QPLGN0160FJZZ X plug 5pin AC
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
SWITCHES
FERRITE BEAD
MISCELLANEOUS PARTS
PWB-B: DUNTKB568WEV0
CRT UNIT
TRANSISTORS
DIODES
COILS
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No.  Description Code
P622 QPLGN0461CEZZA X plug,4pin AB
P651 QPLGN0361CEZZA X plug,3pin AB
P702 QPLGN0269GEZZ X plug 2pin AB
P703 QPLGN0260CEZZ X plug 2pin AB
P721 QPLGN0461CEZZA X plug,4pin AB
P722 QPLGN0461CEZZA X plug,4pin AB
P1101 QPLGN0561CEZZA X plug 5Pin AB
P2401 QPLGN0661CEZZA X plug,6pin AB
RDA361 PRDAR0258PEFW X Heat Sink for IC361 AE
RDA501 PRDARA039WJFW X Heat Sink for IC501 AF
RDA601 PRDARA041WJFW X Heat Sink for Q602 AF
RDA701 PRDAR0279PEFW X Heat Sink for Q701 AD
RDA750 PRDAR5072CEFW X Heat Sink for IC751 AC
RDA1101 PRDAR5072CEFW X Heat Sink for IC1104 AC
RDA1102 PRDAR5072CEFW X Heat Sink for IC1102 AC
RDA1403 PRDAR5072CEFW X Heat Sink for IC1403 AC
RMC2601 RRMCUA022WJZZ X R/C Receiver AE
RY701 RRLYJ0081CEZZ X Relay AE
RY702 RRLYJ0088CEZZ X Relay AE
TP701 QLUGP0102PEZZ X Test point AA
Q850 VS2SC3789//2E X 2SC3789 AD
Q851 VS2SC3789//2E X 2SC3789 AD
Q852 VS2SC3789//2E X 2SC3789 AD
Q853 VS2SC3198-G-1+ X 2SC3198-G AB
Q854 VS2SC3198-G-1+ X 2SC3198-G AB
Q855 VS2SC3198-G-1+ X 2SC3198-G AB
Q890 VS2SC3198-G-1+ X 2SC3198-G AB
Q891 VS2SA1266-Y-1+ X 2SA1266(Y) AB
Q894 VS2SA1266-Y-1+ X 2SA1266(Y) AB
D891 VHD1SS119//-1Y X Diode AA
D892 VHD1SS119//-1Y X Diode AA
D893 VHD1SS119//-1Y X Diode AA
D894 VHD1SS119//-1Y X Diode AA
D895 VHD1SS119//-1Y X Diode AA
D897 VHD1SS119//-1Y X Diode AA
D899 VHD1SS119//-1Y X Diode AA
L852 VP-MK820K0000+ X Peaking,82mH AB
L853 VP-MK820K0000+ X Peaking,82mH AB
L854 VP-MK820K0000+ X Peaking,82mH AB
C850 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C851 VCEA0A1CW107M+ X 100 16V EL. AA
C852 VCKYPA1HB102K+ X 1000p 50V Ceramic AA
C876 VCCSPA1HL391J+ X 390p 50V Ceramic AA
C877 VCCSPA1HL331J+ X 330p 50V Ceramic AA
C878 VCCSPA1HL391J+ X 390p 50V Ceramic AA
C879 VCEA0A1EW476M+ X 47 25V EL. AA
C880 RC-KZ018JCEZZ X 0.01 AC250V Ceramic AB
C890 VCEA0A1CW227M+ X 220 16V EL. AB
C893 VCEA0A1HW106M+ X 10 50V EL. AA
C896 VCEA0A2EW106M+ X 10 250V EL. AC
R849 VRD-RA2BE271JY X 270 1/8W Carbon AA
R850 VRD-RA2BE470JY X 47 1/8W Carbon AA
R851 VRD-RA2BE470JY X 47 1/8W Carbon AA
R852 VRD-RA2BE470JY X 47 1/8W Carbon AA
R854 VRD-RA2BE271JY X 270 1/8W Carbon AA
R855 VRD-RA2BE271JY X 270 1/8W Carbon AA
R856 VRD-RA2BE121JY X 120 1/8W Carbon AA
27SC26B
33
