Sharp 27SC26B User Manual

PWB-B: DUNTKB568WEV0
CRT UNIT
PWB-D: DUNTKB572WEV0
2 LINE Y/C UNIT
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
Ref. No. Part No.  Description Code
R857 VRD-RA2BE121JY X 120 1/8W Carbon AA
R858 VRD-RA2BE121JY X 120 1/8W Carbon AA
R860 VRS-VV3LB123J X 12k 3W M-Ox. AB
R862 VRS-VV3LB123J X 12k 3W M-Ox. AB
R864 VRS-VV3LB123J X 12k 3W M-Ox. AB
R865 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R868 VRD-RM2HD224JY X 220k 1/2W Carbon AA
R870 VRD-RA2BE471JY X 470 1/8W Carbon AA
R871 VRD-RA2BE471JY X 470 1/8W Carbon AA
R872 VRD-RA2BE471JY X 470 1/8W Carbon AA
R873 VRD-RA2BE681JY X 1.5k 1/8W Carbon AA
R874 VRD-RA2BE681JY X 1.5k 1/8W Carbon AA
R875 VRD-RA2BE681JY X 1.5k 1/8W Carbon AA
R876 VRD-RA2BE121JY X 120 1/8W Carbon AA
R877 VRD-RA2BE121JY X 120 1/8W Carbon AA
R878 VRD-RA2BE121JY X 120 1/8W Carbon AA
R879 VRD-RM2HD100JY X 10 1/2W Carbon AA
R880 VRC-MA2HG332KY X 3.3k 1/2W Carbon AB
R881 VRC-MA2HG332KY X 3.3k 1/2W Carbon AB
R882 VRC-MA2HG332KY X 3.3k 1/2W Carbon AB
R883 VRD-RA2BE221JY X 220 1/8W Carbon AA
R884 VRD-RA2BE221JY X 220 1/8W Carbon AA
R885 VRD-RA2BE221JY X 220 1/8W Carbon AA
R886 VRD-RA2BE471JY X 470 1/8W Carbon AA
R887 VRD-RA2BE471JY X 470 1/8W Carbon AA
R888 VRD-RA2BE471JY X 470 1/8W Carbon AA
R890 VRD-RA2BE562JY X 5.6k 1/8W Carbon AA
R891 VRD-RA2BE102GY X 1.0k 1/8W Carbon AA
R892 VRD-RA2BE331GY X 330 1/8W Carbon AA
R894 VRD-RA2BE152JY X 1.5k 1/8W Carbon AA
R895 VRD-RA2EE561JY X 560 25W Carbon AA
R899 VRD-RA2BE222JY X 2.2k 1/8W Carbon AA
P860 QPLGN0441CEZZ X Plug 4Pin AB
P880 QPLGN0641CEZZ X Plug (6 Pins) AB
SC850 QSOCV0937CEZZ X CRT Socket AE
IC1401 VHITC90A45F-1Y X TC90A45AF AM
Q1401 VS2SD601AR/-1Y X 2SD601AR AB
Q1402 VS2SD601AR/-1Y X 2SD601AR AB
Q1404 VS2SB709AR/-1Y X 2SB709AR AB
L1401 VP-XF100K0000Y X Peaking,10mH AA
L1402 VP-XF100K0000Y X Peaking,10mH AA
L1403 VP-XF100K0000Y X Peaking,10mH AA
L1404 VP-XF220K0000Y X Peaking,22mH AA
L1405 VP-XF220K0000Y X Peaking,22mH AA
L1408 VP-XF100K0000Y X Peaking,10mH AA
C1401 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1402 VCEA0A1AW227M+ X 220 10V EL. AB
C1403 VCCCCY1HH330JY X 33p 50V Ceramic AA
C1404 VCCCCY1HH181JY X 180p 50V Ceramic AA
C1405 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1406 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1407 VCKYCY1HB103KY X 0.01 50V Ceramic AA
MISCELLANEOUS PARTS
INTEGRATED CIRCUITS
TRANSISTORS
COILS
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
MISCELLANEOUS PARTS
Ref. No. Part No.  Description Code
C1408 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1409 VCEA0A1CW476M+ X 47 16V EL. AA
C1410 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1411 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1412 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1413 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1414 VCE9GA1HW105M+ X 1 50V EL. AB
C1415 VCCCCY1HH120JY X 12p 50V Ceramic AA
C1416 VCCCCY1HH3R0CY X 3p 50V Ceramic AA
C1417 VCCCCY1HH270JY X 27p 50V Ceramic AA
C1418 VCCCCY1HH120JY X 12p 50V Ceramic AA
C1419 VCCCCY1HH3R0CY X 3p 50V Ceramic AA
C1420 VCCCCY1HH270JY X 27p 50V Ceramic AA
C1423 VCFYFA1HA474J+ X 0.47 50V Mylar AB
C1424 VCEA0A1CW107M+ X 100 16V EL. AA
C1425 VCCCCY1HH820JY X 82p 50V Ceramic AA
C1429 VCEA0A1CW107M+ X 100 16V EL. AA
C1430 VCKYCY1CB104KY X 0.1 16V Ceramic AA
C1431 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1432 VCKYCY1HB103KY X 0.01 50V Ceramic AA
R1401 VRS-CY1JF821JY X 820 1/16W M-Ox. AA
R1402 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1403 VRS-CY1JF361JY X 360 1/16W M-Ox. AA
R1415 VRS-CY1JF391JY X 390 1/16W M-Ox. AA
R1416 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1417 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R1420 VRN-RL3LB2R7J+ X 2.7 3W M-Film AC
R1421 VRS-CY1JF152FY X 1.5k 1/16W M-Ox. AA
R1423 VRS-CY1JF102FY X 1k 1/16W M-Ox. AA
R1427 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1428 VRD-RA2BE332JY X 3.3k 1/8W Carbon AA
R1429 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1430 VRS-CY1JF151JY X 150 1/16W M-Ox. AA
P1401 QPLGZ0810CEZZ X plug 32" AD
27SC26B
34
