Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
43
27U-F500
27U-F810
PICTURE TUBE
★ MARK: SPARE PARTS-DELIVERY SECTION
' MARK: X-RAY RELATED PARTS
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics iden-
tified in this manual ; electrical components having such features are
identified by å and shaded areas in the Replacement Parts Lists and
Schematic Diagrams. The use of a substitute replacement part which
does no have the same safety characteristic as the factory recom-
mended replacement parts shown in this service manual may create
shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the fol-
lowing informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order. For
location of SHARP Parts Distributor, Please call Toll-Free; 1-
800-BE-SHARP
Ref. No. Part No. ★ Description Code
'åV101 VB68LUW696X2E J Picture Tube(With D.Y) CY
å L703 RCiLG0056PEZZ R Degaussing Coil AS
or
RCiLGA023WJZZ
LHLDW0102GJKZ X Wire Holder, x5 AC
å QEARCA010WJZZ X Grounding Strap AH
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
27U-F500
PWB-A DUNTKA526WED0 – MAIN Unit —
PWB-B DUNTKA527WEB4 – CRT Unit —
PWB-C DUNTKA602WEA1 – AV Unit —
PWB-H DUNTKB225WEA2 – DF MODULE Unit —
PWB-S DUNTKB224WEA2 – MTS MODULE Unit —
27U-F810
PWB-A DUNTKA526WEC8 – MAIN Unit —
PWB-B DUNTKA527WEB4 – CRT Unit —
PWB-C DUNTKA602WEA1 – AV Unit —
PWB-H DUNTKB225WEA2 – DF MODULE Unit —
PWB-K DUNTKB223WEA0 – 2-TUNER Unit —
PWB-R DUNTKA533WEA1 – P-IN-P Unit —
PWB-S DUNTKB224WEA0 – MTS MODULE Unit —
PWB-A: DUNTKA526WED0(27U-F500)
PWB-A: DUNTKA526WEC8(27U-F810)
MAIN UNIT
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTUVTST5UF740 X Tuner AX
or
VTUENV56DA1G63
INTEGRATED CIRCUITS
å IC201 RH-iX3395CEN2 J TB1252CN AY
å IC361 VHiAN5277//-1 J AN5277 AN
å IC501 VHiTA8427K/-1 J TA8427K AL
å IC701 VHiTEA1507/-1 J TEA1507P/N1 AL
å IC702 RH-FX0008GEZZ J PC123FY8 AE
å IC703 VHiSE120N//-1 J SE120N AG
IC751 VHiSTV8164+-1 X I.C. AM
IC2001 RH-iXA192WJZZ X TMPA8700CSF AY
IC2040 VHiKiA7045A-1 J KIA7045AP AE
or
VHiKiA7045P-1
IC2101 VHiM24C16B/-1 J M24C16-BN6 AG
TRANSISTORS
Q201 VS2SC2735//1E J 2SC2735 AC
Q205 VS2PD601AR/-1 J 2PD601AR AB
Q206 VS2PD601AR/-1 J 2PD601AR AB
Q361 VS2PB709AR/-1 J 2PB709AR AB
Q402 VS2PB709AR/-1 J 2PB709AR AB
Q405 VS2PD601AR/-1 J 2PD601AR AB
Q410 VS2PD601AR/-1 J 2PD601AR (27U-F810) AB
Q459 VS2PB709AR/-1 J 2PB709AR (27U-F500) AB
Q460 VS2PB709AR/-1 J 2PB709AR (27U-F500) AB
Q471 VS2PD601AR/-1 J 2PD601AR AB
Q472 VS2PD601AR/-1 J 2PD601AR AB
Q473 VS2PD601AR/-1 J 2PD601AR AB
Q474 VS2PD601AR/-1 J 2PD601AR AB
Q601 VS2SC2482//-1 J 2SC2482 AD
å Q602 VS2SD2581++2E J 2SD2581++ AM
or
VS2SD2646++2E
Q616 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
Q634 VS2SC3198-G-1 J 2SC3198-G AA
Q650 VS2SA1266-Y-1 J 2SA1266-Y AA
Q672 VS2SA1266-Y-1 J 2SA1266-Y AA
Q673 VS2SD2045//-1 J 2SD2045 AL
å Q701 VSST6NC60FP1E X ST6NC60FP AN
Q727 VS2SC3333//-1 J 2SC3333 AG
Q728 VS2SA1091-O1A J 2SA1091 AA
Q729 VS2SA1266-Y-1 J 2SA1266-Y AA
Q730 VS2SC3198-G-1 J 2SC3198-G AA
Q751 VS2SC3198-G-1 J 2SC3198-G AA
Q752 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
Q753 VS2SC3198-G-1 J 2SC3198-G AA
Q801 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
Q901 VSiMX1C/C//-1 J IMX1C/C AB
Q902 VSiMX1C/C//-1 J IMX1C/C AB
Q903 VSiMX1C/C//-1 J IMX1C/C AB
Q908 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
Q2002 VS2SA1266-Y-1 J 2SA1266-Y AA
Q2059 VS2SC3198-G-1 J 2SC3198-G AA
Q2060 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
