8
27U-F500
27U-F810
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE RANGE
ADJUSTMENT CONTENTS
Table - A
V01 PICTURE 3(03h) 0-15(00h-0Fh)
V02 TINT 62(3Eh) 0-127(00h-7Fh)
V03 COLOR 45(2Dh) 0-127(00h-7Fh)
V04 SCREEN 16(10h) 0-31(00h-1Fh) Must be set to “10”
V05 BRIGHT 77(4Dh) 0-127(00h-7Fh)
V06 R CUT-OFF 64(40h) 64-255(40h-FFh)
V07 G CUT-OFF 64(40h) 64-255(40h-FFh)
V08 B CUT-OFF 64(40h) 64-255(40h-FFh)
V09 G DRIVE 64(40h) 0-127(00h-7Fh)
V10 B DRIVE 64(40h) 0-127(00h-7Fh)
V11 SHARP 20(14h) 0-63(00h-3Fh) Must be set to “1E”
V12 N PHASE 1(01h) 0-3 (00h-03h) Must be set to “01”
V13 DC RESTORATION 0(00h) 0-3 (00h-03h) Must be set to “03”
V14 BLACK STRETCH 3(03h) 0-3 (00h-03h) Must be set to “03”
V15 ABL START POINT 3(03h) 0-3 (00h-03h) Must be set to “03”
V16 ABL GAIN 2(02h) 0-3 (00h-03h) Must be set to “02”
V17 γ POINT 0(00h) 0-3 (00h-03h) Must be set to “02”
V18 Y-MUTE/V-STOP 0(00h) 0-2 “00”=Nomal,“01”=No-Y,“02”=No-Y&No-Vertical
V19 ENERGY SAVE 40(28h) 0-63(00h-3Fh) Must be set to “28”
V20 RTONE-G – –
V21 RTONE-B – –
V22 RTONE-G – –
V23 RTONE-B – –
V24 LOW-G 247(F7h) 0-255(00h-FFh) Must be set to “F7”
V25 LOW-B 232(E8h) 0-255(00h-FFh) Must be set to “E8”
V26 ML-G 0(00h) 0-255(00h-FFh) Must be set to “00”
V27 ML-B 249(F9h) 0-255(00h-FFh) Must be set to “F9”
V28 HIGH-G 3(03h) 0-255(00h-FFh) Must be set to “03”
V29 HIGH-B 6(06h) 0-255(00h-FFh) Must be set to “06”
V30 WPS 1(01h) 0-1 Must be set to “01”
V31 RGB CONTRAST 31(20h) 0-63(00h-3Fh) Must be set to “31”
V32 Y-DL 2(02h) 0-7(00h-07h) Must be set to “02”
V33 Y-DL-INPUT 1(01h) 0-7(00h-07h) Must be set to “01”
V34 VSM GAIN 7(07h) 0-7(00h-07h) Must be set to “07”
V35 N COMB 1(01h) 0-1 Must be set to “01”
V36 BPF/TOF-INPUT 0(00h) 0-1 Must be set to “01”
V37 CORING 0(00h) 0-1 Must be set to “00”
V38 VSM PHASE 0(00h) 0-1 Must be set to “00”
V39 COLOR γ 0(00h) 0-1 Must be set to “01”
V40 SHARP-INPUT 20(14h) 0-63(00h-3Fh) Must be set to “1E”
V41 TINT-INPUT 62(3Eh) 0-127(00h-7Fh)
V42 PICTURE-COMPONENT 3(03h) 0-15(00h-0Fh)
V43 TINT-COMPONENT 16(10h) 0-31(00h-1Fh) Must be set to “10”
V44 COLOR-COMPONENT 48(30h) 0-127(00h-7Fh) Must be set to “44”
V45 BRIGHT-COMPONENT 74(4Ah) 0-127(00h-7Fh)
V46 R CUT OFF-COMPONENT 64(40h) 64-255(00h-FFh)
V47 G CUT OFF-COMPONENT 64(40h) 64-255(00h-FFh)
V48 B CUT OFF-COMPONENT 64(40h) 64-255(00h-FFh)
V49 G DRIVE-COMPONENT 64(40h) 0-127(00h-7Fh)
V50 B DRIVE-COMPONENT 64(40h) 0-127(00h-7Fh)
V51 SHARP-COMPONENT 20(14h) 0-63(00h-3Fh) Must be set to “1E”
V52 N PHASE-COMPONENT 01(01h) 0-3 (00h-03h) Must be set to “01”
V53 C-TRAP 0(00h) 0-1 Must be set to “00”
V54 ANT-B PICTURE 3(03h) 0-15(00h-0Fh)
V55 ANT-B TINT 62(3Eh) 0-127(00h-7Fh)
V56 ANT-B COLOR 45(2Dh) 0-127(00h-7Fh)
V57 ANT-B SHARP 20(14h) 0-63(00h-3Fh) Must be set to “1E”
V58 ANT-B BRIGHT 77(4Dh) 0-127(00h-7Fh)
R01 RF-AGC 36(24h) 0-63(00h-3Fh)
R02 PIF VCO coil – –
R03 RF-AGC REF 5C(5Ch) 0-255(00h-FFh) Must be set to “5C”
D01 V POSITION 0(00h) 0-7 (00h-07h)
D02 H POSITION 16(10h) 0-31(00h-1Fh)
D03 V SIZE 18(12h) 0-63(00h-3Fh)
D04 H SIZE 31(1Fh) 0-63(00h-3Fh) Must be set to “38”
D05 V-LINEARITY 7(07h) 0-15(00h-0Fh)
