35
Specifications
MODEL 32R-S50 36R-S50
Receiving System NTSC
Reception Channels
AIR VHF 2-13 ch
UHF 14-69 ch
CATV 1-125 ch
Channel Tuning 181-channel Reception PLL tuning system
Antenna Input Impedance VHF/UHF 75 ohm Unbalance
Screen Size 32˝ Diagonally Measured 36˝ Diagonally Measured
Terminals Audio/video input x 2 (front x 1, rear x 1)
Sound Output 3.0W (RMS) x 2
Power Source AC 120V, 60 Hz
Power Consumption 137 W 162 W
Dimensions 30
21
/
64
˝ x 26
7
/
8
˝ x 21
57
/
64
˝ 34
47
/
64
˝ x 29
55
/
64
˝ x 24
25
/
32
˝
[(w) x (H) x (D)]mm [770.0 x 682.0 x 556.0] [882.0 x 758.0 x 629.0]
Weight (approx.) 114.6 lbs. (52.0 kg) 154.0 lbs. (70.0 kg)
• Design and specifications are subject to change without notice.
