Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
26
32U-S50B
32U-S60B
PWB-A: DUNTKB567WEV6
MAIN UNIT(Continued)
D708 VHD1SS244//-1∗ X 1SS244 AA
å D709 RH-DXA006WJZZ X Diode AB
D712 RH-DX0468CEZZ X Diode AB
D725 RH-DX0302CEZZ∗ X Diode AB
D726 RH-DX0461CEZZ X Diode AB
D751 VHD1SS119//-1∗ X 1SS119 AA
D752 VHD1SS119//-1∗ X 1SS119 AA
D753 VHD1SS119//-1∗ X 1SS119 AA
D754 VHD1SS119//-1∗ X 1SS119 AA
D755 VHD1SS119//-1∗ X 1SS119 AA
D756 VHD1SS119//-1∗ X 1SS119 AA
D757 RH-EX0619GEZZ∗ X Zener Diode, 6.2V AB
D905 RH-EX0631GEZZ∗ X Zener Diode, 9.1V AB
D906 RH-EX0631GEZZ∗ X Zener Diode, 9.1V AB
D907 RH-EX0631GEZZ∗ X Zener Diode, 9.1V AB
D908 RH-EX0631GEZZ∗ X Zener Diode, 9.1V AB
D2001 VHD1SS119//-1∗ X 1SS119 AA
D2040 RH-EX0619GEZZ∗ X Zener Diode, 6.2V AB
D2060 RH-EX0619GEZZ∗ X Zener Diode, 6.2V AB
PACKAGED CIRCUITS
TH501 RH-HZ0004GEZZ+ X Thermistor AB
å VA701 RH-VXA009WJZZ X Varistor AB
å PR701 RMPTP0092CEZZ X Packaged Circuit AD
X801 RCRSAA010WJZZ X Crystal AC
FILTERS AND COILS
CF302 RFiLC0449CEZZ+ X Filter AB
CF401 RFiLC0446CEZZ+ X Filter AB
L51 VP-CF100K0000∗ X Peaking, 10µHAB
L201 VP-XF1R2K0000∗ X Peaking, 1.2µHAA
L203 VP-XF100K0000∗ X Peaking, 10µHAA
L204 VP-XF100K0000∗ X Peaking, 10µHAA
L231 VP-XF680K0000∗ X Peaking, 68µHAA
L301 VP-XF8R2K0000∗ X Peaking, 8.2µHAA
L401 VP-XF100K0000∗ X Peaking, 10µHAA
L671 RCiLZ1005CEZZ X Coil AD
L672 RCiLZ1027CEZZ X Coil AD
L701 RCiLF0345CEZZ X Coil AD
L702 RCiLF0345CEZZ X Coil AD
L705 RCiLP0179CEZZ+ X Coil AB
L728 RCiLP0179CEZZ+ X Coil AB
L729 RCiLP0179CEZZ+ X Coil AB
L801 VP-XF100K0000∗ X Peaking, 10µHAA
L802 VP-XF100K0000∗ X Peaking, 10µHAA
L2040 RCiLBA003WJZZ X Oscillation Coil AB
SF201 RFiLC0405CEZZ X Filter AD
TRANSFORMERS
å T601 RTRNZ0057PEZZ X Transformer AD
'åT602 RTRNFA038WJZZ X H-Volt Transformer AU
å T702 RTRNWA071WJZZ X Transformer AG
CAPACITORS
C53 VCEA0A1HW105M+X 1 50V Electrolytic AA
C54 VCEA0A1HW475M+X 4.7 50V Electrolytic AA
C55 VCEA0A0JW108M+ X 1000 6.3V Electrolytic AB
C58 VCKYCY1HF103Z∗ X 0.01 50V Ceramic AA
C59 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C101 VCEA0A0JW108M+ X 1000 6.3V Electrolytic AB
C103 VCEA0A1CW108M+X 1000 16V Electrolytic AB
C201 VCKYCY1HB102K∗ X 1000p 50V Ceramic AA
C202 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C203 VCKYCY1HB102K∗ X 1000p 50V Ceramic AA
C223 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C224 VCEA0A1HW474M+X 0.47 50V Electrolytic AA
C225 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C227 VCEA0A1HW106M+X 10 50V Electrolytic AA
C228 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C229 VCEA0A1CW477M+X 470 16V Electrolytic AB
C231 VCEA0A1EW476M+X 47 25V Electrolytic AA
C232 VCKYCY1HB222K∗ X 2200p 50V Ceramic AA
C233 VCEA0A1HW474M+X 0.47 50V Electrolytic AA
C234 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C235 VCEA0A1HW106M+X 10 50V Electrolytic AA
C251 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C252 VCEA0A1EW476M+X 47 25V Electrolytic AA
C302 VCCCCY1HH151J∗ X 150p 50V Ceramic AA
C303 VCCCCY1HH330J∗ X 33p 50V Ceramic AA
C304 VCEA0A1HW475M+X 4.7 50V Electrolytic AA
C306 VCCCCY1HH330J∗ X 33p 50V Ceramic AA
C307 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C312 VCEA0A1EW476M+X 47 25V Electrolytic AA
C360 VCEA0A1HW475M+X 4.7 50V Electrolytic AA
C361 VCEA0A1HW105M+X 1 50V Electrolytic AA
C362 VCKYCY1EB223K∗ X 0.022 25V Ceramic AA
C363 VCKYCY1EB223K∗ X 0.022 25V Ceramic AA
C364 VCEA0A1EW227M+X 220 25V Electrolytic AB
C365 VCEA0A1HW105M+X 1 50V Electrolytic AA
C366 VCEA0A1HW106M+X 10 50V Electrolytic AA
C367 VCEA0A1VW108M+X 1000 35V Electrolytic AB
C368 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C369 VCEA0A1CW227M+X 220 16V Electrolytic AB
C370 VCEA0A1CW227M+X 220 16V Electrolytic AB
C371 VCEA0A1EW108M+X 1000 25V Electrolytic AB
C372 VCEA0A1EW108M+X 1000 25V Electrolytic AB
C373 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C375 VCEA0A1HW475M+X 4.7 50V Electrolytic AA
C429 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C433 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C434 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C435 VCEA0A1HW105M+X 1 50V Electrolytic AA
C436 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C437 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C438 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C439 VCEA0A1HW106M+X 10 50V Electrolytic AA
C440 VCFYFA1HA224J+ X 0.22 50V Mylar AB
C451 VCQYTA2AA104K+ X 0.1 100V Mylar AB
C452 VCEA0A1EW336M+X 33 25V Electrolytic AA
C502 VCEA0A1VW477M+X 470 35V Electrolytic AB
C504 VCEACA1HC474M+X 0.47 50V Electrolytic AB
C505 VCEA0A1HW474M+X 0.47 50V Electrolytic AA
C506 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C507 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C510 RC-FZ0272CEZZ+ X 0.39 100V Mylar AB
C512 VCEA0A1EW476M+X 47 25V Electrolytic AA
C514 VCEA0A1VW107M+X 100 35V Electrolytic AB
C516 VCKYCY1HB472K∗ X 4700p 50V Ceramic AA
C518 VCQYTA2AA473J+ X 0.047 100V Mylar AB
C522 VCFYFA1HA334J+ X 0.33 50V Mylar AB
C523 VCEA0A1HW105M+X 1 50V Electrolytic AA
C601 VCEA0A1CW477M+X 470 16V Electrolytic AB
C602 VCKYCY1CF104Z∗ X 0.1 16V Ceramic AA
C603 VCEA0A1HW225M+X 2.2 50V Electrolytic AA
C604 VCKYCY1EB223K∗ X 0.022 25V Ceramic AA
C606 VCKYPA2HB561K+ X 560p 500V Ceramic AB
C607 VCKYPA1HB472K+ X 4700p 50V Ceramic AA
C608 RC-KZ0033CEZZ X 150p 2kV Ceramic AB
'åC609 VCFPVC3ZA203H X 0.02 1600V M.Polypro AB
C611 VCEA0A1EW477M+X 470 25V Electrolytic AB
C614 VCEA0A1EW108M+X 1000 25V Electrolytic AB
C615 VCFYSB2EB823J X 0.082 250V Mylar AB
C616 VCKYPA2HB471K+ X 470p 500V Ceramic AB
C617 VCEA0A1HW474M+X 0.47 50V Electrolytic AA
C622 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C623 VCEA4A2EN106M+ X 10 250V Electrolytic AB
C652 VCEA0A1HW476M+X 47 50V Electrolytic AB
C653 VCEA0A1HW106M+X 10 50V Electrolytic AA
C674 VCKYCY1HB391K∗ X 390p 50V Ceramic AA
C675 VCEA0A1HW106M+X 10 50V Electrolytic AA
C677 RC-FZ0377CEZZ X 4.7 50V Mylar AD
'åC678 VCQPPC2GB563J X 0.056 400V Plastic Film AB
C681 VCFPFA2EB684J X 0.68 250V AB
C682 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C685 VCQYTA1HM333J+ X 0.033 50V Mylar AA
å C701 RC-FZA022WJZZ X 0.22 AC250V AB
C702 RC-KZ0029CEZZ+ X 0.01 AC250V Ceramic AB
