Sharp 32U-S50B Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
25
32U-S50B
32U-S60B
PICTURE TUBE
★ MARK: SPARE PARTS-DELIVERY SECTION
' MARK: X-RAY RELATED PARTS
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics iden-
tified in this manual ; electrical components having such features are
identified by å and shaded areas in the Replacement Parts Lists and
Schematic Diagrams. The use of a substitute replacement part which
does no have the same safety characteristic as the factory recom-
mended replacement parts shown in this service manual may create
shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the fol-
lowing informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order. For
location of SHARP Parts Distributor, Please call Toll-Free; 1-
800-BE-SHARP
Ref. No. Part No. ★ Description Code
å V101 VB80AEJ15X/1E X Picture Tube CN
å L703 RCiLGA045WJZZ X Degaussing Coil AN
QEARC3102MEZZ X Grounding Strap AD
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTKB567WEV6 – MAIN Unit —
PWB-B DUNTKB568WEV1 – CRT Unit —
PWB-D DUNTKB572WEV0 – 2 LINE Y/C Unit —
PWB-A: DUNTKB567WEV6
MAIN UNIT
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTUVT1T5UF202 X Tuner AR
INTEGRATED CIRCUITS
IC101 VHiPQ050ES1-1+ X PQ050ES1MXP AB
'åIC201 VHiTB1253AN-1 X TB1253AN AP
å IC361 VHiAN5277//-1 X AN5277 AG
å IC501 VHiTDA8177+-1 X TDA8177 AE
IC602 VHiBA15218F2E∗ X BA15218F-E2 AB
å IC701 VHiTEA1507/-1 X TEA1507P/N1 AE
å IC702 RH-FXA003WJZZ X PC123Y82 AB
'åIC703 VHiSE125N//-1 X SE125N AD
IC751 VHiPQ09RD11-1 X PQ09RD11 AD
IC900 VHiCXA2089Q-2Y X CXA2089Q-6T AK
IC1403 VHiPQ05RD11-1 X PQ05RD11 AD
IC2001 RH-iXA418WJZZQ X TMP88CS38BFG AN
IC2040 VHiKiA7045A-1+ X KIA7045AP AB
IC2101 VHiBR2416E2-1∗ X BR24C16F AD
IC3001 VHiCXA2074Q-1∗ X CXA2074Q AP
TRANSISTORS
Q201 VS2SC2735//1E∗ X 2SC2735 AB
Q361 VS2SB709AR/-1∗ X 2SB709AR AA
Q401 VS2SD601AR/-1∗ X 2SD601AR AA
Q402 VS2SB709AR/-1∗ X 2SB709AR AA
Q451 VS2SA1266-Y-1+ X 2SA1266-Y AB
Q460 VSRT1N441C/-1∗ X RT1N441C AB
Q601 VS2SC2482//-1+ X 2SC2482 AB
å Q602 VS2SD2646++1E X 2SD2646 AG
Q672 VS2SA1266-Y-1+ X 2SA1266-Y AB
Q673 VS2SD1830//1E X 2SD1830 AD
å Q701 VSSPA11N603-1 X SPA11N603 AK
Q751 VS2SC3198-G-1+ X 2SC3198-G AB
Q755 VS2SD601AR/-1∗ X 2SD601AR AA
Q756 VS2SD601AR/-1∗ X 2SD601AR AA
Q757 VS2SC3198-G-1+ X 2SC3198-G AB
Q758 VS2SA1266-Y-1+ X 2SA1266-Y AB
Q802 VS2SD601AR/-1∗ X 2SD601AR AA
Q907 VS2SD601AR/-1∗ X 2SD601AR AA
Q908 VS2SB709AR/-1∗ X 2SB709AR AA
Q910 VS2SB709AR/-1∗ X 2SB709AR AA
Q2060 VS2SD601AR/-1∗ X 2SD601AR AA
Q2201 VS2SD601AR/-1∗ X 2SD601AR AA
Q2211 VS2SD601AR/-1∗ X 2SD601AR AA
DIODES
D52 RH-EX0676GEZZ∗ X Zener Diode, 32V AB
D103 RH-DX0441CEZZ∗ X Diode AA
D361 VHD1SS119//-1∗ X 1SS119 AA
D362 VHD1SS119//-1∗ X 1SS119 AA
D412 RH-EX0614GEZZ∗ X Zener Diode, 5.6V AB
D413 RH-EX0614GEZZ∗ X Zener Diode, 5.6V AB
D414 RH-EX0614GEZZ∗ X Zener Diode, 5.6V AB
D454 RH-EX0628GEZZ∗ X Zener Diode, 8.2V AB
D455 VHD1SS119//-1∗ X 1SS119 AA
D501 RH-DX0302CEZZ∗ X Diode AB
D502 VHD1SS119//-1∗ X 1SS119 AA
D510 RH-DX0441CEZZ∗ X Diode AA
å D605 RH-DX0255CEZZ X Diode AD
å D606 RH-DX0302CEZZ∗ X Diode AB
D607 RH-DX0471CEZZ∗ X Diode AB
D621 RH-EX0631GEZZ∗ X Zener Diode, 9.1V AB
å D622 RH-DX0131CEZZ∗ X Diode AB
'åD651 VHD1SS244//-1∗ X 1SS244 AA
'åD652 RH-EX0641GEZZ∗ X Zener Diode, 12V AB
'åD653 VHD1SS119//-1∗ X 1SS119 AA
'åD654 VHD1SS119//-1∗ X 1SS119 AA
å D673 RH-DXA006WJZZ X Diode AB
å D701 RH-DX0477CEZZ X Diode AE
D707 VHD1SS244//-1∗ X 1SS244 AA
