Sharp 32U-S50B Service Manual

9
32U-S50B
32U-S60B
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
RANGE
NOTE
EX1 FAO VOLUME 0-50 (00h-32h) 36 (24h) 24
EX2 CC-POSITION 0-127 (00h-7Fh) 27 (1Bh) 1C
EX3 INT 0-255 (00h-FFh) 122 (7Ah) Interrupt period adjustment. 7A
EX4 A-ATT 0-127 (00h-7Fh) 90 (5Ah) 5A
EX5 TUNER data 0-3 (00h-03h) 0 (00h) 00
EX6 Think chip-Slice LEVEL 0-255 (00h-FFh) 54 (36h) 12
EX7 RLY DELAY TIME 0-255 (00h-FFh) 0 (00h) For the power control 00
EX8 ADG ON TIME 0-255 (00h-FFh) 10 (0Ah) For the power control 0A
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE RANGE
OP1 OPTION1 0-255 (00h-FFh) 247 (F7h) B0
OP2 OPTION2 0-255 (00h-FFh) 253 (FDh) 08
OP3 OPTION3 0-255 (00h-FFh) 15 (0Fh) 0C
B. SPECIAL SETTING
C. OPTION SETTING
FIXED VALUE
(HEX)
NOTE
FIXED VALUE
(HEX)
NECESSARY UNNECESSARY
ADJUSTMENT
PART REPLACED
IC2001
IC201
X
Data is stored in IC2101.
The adjustment is needed to compensate for characteristics of parts
including IC201 and MTS level (M01).
Holding down both the VOL-up and CH-up buttons on the TV set at service mode for more than 2 seconds will
automatically write the above initial values into IC2101.
NOTES
X
IC2101
IC3001
CRT
Holding down both the VOL-up and CH-up buttons on the TV set in
the service mode for more than 2 seconds will automatically write the
above initial values into IC2101 Then perform a complete adjustment.
Adjust items related to picture tube only.
Adjust items related to MTS only (M01~M20).
X
X
X
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
RANGE
M01 INPUT LEVEL 0-15 (00h-0Fh) 7 (07h)
M02 MTS VCO 0-63 (00h-3Fh) 38 (26h)
M03 FILTER 0-63 (00h-3Fh) 36 (24h)
M04 WIDEBAND 0-63 (00h-3Fh) 28 (1Ch)
M05 SPECTRAL 0-63 (00h-3Fh) 23 (17h)
D. SOUND ADJUSTMENT
NOTE
FIXED VALUE
(HEX)
