Sharp AE-A7FHR - Page 29

AYAP7FHR
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] INDOOR UNIT PARTS
1-1 DPWBFA411JBKZ BM Control unit[AYAP7FHR]
1-1 DPWBFA396JBKZ BM Control unit[AYAP9FHR]
1-5 QACC-A305JBZZ AN Power supply cord
1-6 QTANZA027JBZZ AQ Terminal board
1-7 QW-VZE874JBZZ AF Earth lead
1-8 RTHM-A300JBE0 AN Thermistor
1-9 QTANZA022JBZZ AH Terminal board
1-10 FPWBFA586JBKZ AZ Display c-b-u k
2-1 CHLD-A067JBK0 AL Bearing ass'y
2-2 NFANCA099JBEZ BC Cross flow fan
2-3 CMOT-A443JBKZ BE Fan motor
2-4 PCOV-B072JBFZ AN Motor cover
2-6 PCOV-B073JBFA AN Control box cover
2-7 PCOV-B074JBPZ AM Control box cover
2-8 LHLD-A500JBFZ AC Thermistor holder
2-9 PBOX-A442JBFA BH Control box
2-10 DCHS-A530JBKZ BG Cabinet sub ass'y
2-11 LHLD-A478JBFZ AF Tube holder
2-12 LHLD-A303JBFA AD Tube cover
2-13 PPLTNA081JBPZ AX Mounting angle
2-14 LHLD-A716JBFA AF LED holder
2-15 PCOV-B076JBFZ AF LED guide
2-16 PFILMA204JBEZ AM Air filter
2-17 PCOV-B075JBPZ AR Control box cover
2-18 LHLD-A756JBFA AF Cord holder
2-19 PCOV-B144JBPZ AK Cord holder cover
2-20 CSRA-A624JBKZ BX Drain pan ass'y
2-20-1 CHOS-A018JBKZ AN Drain hose ass'y
2-20-1A PHOS-A044JBEZ AM Drain hose
2-20-1B LPLT-A058JBPZ AC Hose holder
2-20-2 MLOV-A299JBFA AC Vertical louver
2-20-3 MJNTPA082JBFA AC Louver link
2-20-4 DSRA-A265JBKZ BL Drain pan
2-20-5 LPFT-A152JBFZ AF
Dorain joint L
2-20-6 PGUMMA110JBE0 AD Drain plug
2-20-7 LHLD-A720JBFA AK PCI holder
2-20-8 CKITTA071AKKZ BD Plasmacluster unit
2-20-9 LHLD-A719JBFA AF Lead wire guide
2-20-10 RMOT-A115JBEZ AS Louver motor
2-20-11 LPFT-A151JBFZ AF Drain joint
2-20-12 MLOV-A396JBFA AX H-louver
2-20-13 NBRG-A026JBFA AB Louver bushing
2-20-14 LHLD-A197JBFM AC Louver holder
2-21 CPNL-A515JBKZ BC Open panel ass'y
2-21-1 HBDG-A002KKEA AE Badge
2-21-2 HPNL-A721JBRA AU Open panel
2-22 DWAK-A915JBKZ BB Front panel ass'y
2-22-1 GWAK-A317JBFA AZ Front panel
2-22-2 PCOV-B077JBFA AK Screw cover
2-22-3 HDECQA125JBRB AZ Display panel
2-22-4 FCOV-A194JBFA AK Front cover L
2-22-5 FCOV-A193JBFA AF Cover
2-22-6 FCOV-A195JBFA AK Front cover R
2-23 TLABCC053JBRZ AF Wiring diagram
2-24 PCOV-A300JBF0 AB Thermo holder cover
3-1 CPIPCA918JBKZ AZ Tube ass'y
3-2 CEVA-A115JBKZ BU Evaperator sub ass'y
3-3 PVLV-0341JBE0 AG Flare union 2S
3-4 PVLV-0342JBE0 AH Flare union 3S
