Sharp AE-X10BE-C Service Manual

48
AY-XP08/10/13CE
AE-X08/10BE-C
AE-X13BE
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
3-14 LX-NZA136JBE0 Special nut [AE-X08BE-C] 1 AL
3-15 GLEG-A076JBE0 Compressor cushion [AE-X08BE-C] 3 AK
3-15 GLEG-A029JBE0 Compressor cushion [AE-X10BE-C/X13BE] 3 AE
3-16 PSPF-A767JBEZ Compressor cover [AE-X08BE-C/X13BE] 1 AV
3-16 PSPF-A828JBEZ Compressor cover [AE-X10BE-C] 1 AQ
3-17 PSPF-A830JBEZ Compressor cover [AE-X08BE-C] 1 AE
3-17 PSPF-A829JBEZ Compressor cover [AE-X10BE-C] 1 AF
3-17 PSPF-A768JBEZ Compressor cover [AE-X13BE] 1 AG
3-18 PSEN-A004JBK0 Flare nut ass’y 1 AE
3-19 PSEN-A005JBK0 Flare nut ass’y [ AE-X08BE-C/X10BE-C] 1 AG
3-19 PSEN-A016JBK0 Flare nut ass’y [AE-X13BE] 1 AR
3-20 PGUM-A135JBEZ Compressor sheet 1 AG
3-21 PSPF-A797JBE0 Compressor cover 1 AG
3-22 PMUF-A026JBE0 Muffler [AE-X08BE-C/X10BE-C] 1 AL
3-22 PMUF-A054JBEZ Muffler [AE-X13BE] 1 AT
3-23 PVLVXA044JBEZ Reverse valve [AE-X08BE-C/X10BE-C] 1 BG
3-23 PVLVXA039JBE0 Reverse valve [AE-X13BE] 1 BD
3-24 LX-NZA037JBE0 Bonnet [AE-X13BE only] 1 AG
3-25 CCIL-A112JBEZ Coil [AE-X08BE-C, AE-X10BE-C] 1 AX
3-25 CCIL-A097JBEZ Coil [AE-X13BE] 1 AV
SCREWS AND NUTS
4- 1 LX-BZA140JBE0 Special screw 32 AB
4- 2 LX-BZA072JBE0 Special screw (for 2/3 way valve unit) 4 AB
4- 3 XTTSD40P14000 Tapping screw 1 AA
4- 4 LX-BZA166JBE0 Special screw 3 AB
4- 5 LX-NZA026JBE0 Special nut (for compressor) 3 AC
4- 6 LX-BZA075JBE0 Special screw 2 AA
4- 7 LX-BZA140JBE0 Special screw 7 AB
4- 8 LX-BZA075JBE0 Special screw (for Earth) 1 AA
4- 9 XBPSD40P20JS0 Machine screw (for IPM) 5 AB
4-10 LX-NZA135JBE0 Special nut (for propeller fan) 1 AC
4-11 XBPSD40P20J00 Machine screw (for DB1) 1 AA
4-12 XCTSD40P12000
Tapping screw (for Terminal board ass’y angle, for capacitor clamp) 2AA
4-13 XTPSD30P12XS0 Tapping screw 3mm x 16mm (for PWB assembly) 2 AC
4-14 LX-BZA292JBEZ Tapping screw 3mm x 16mm (for Top cover) 8 AC
4-15 XTTSD40P16000 Tapping screw (for Heatsink) 1 AA
4-16 LX-BZA140JBE0 Special screw (for Heatsink holder) 1 AB
4-17 XCTSD40P16000 Tapping screw (for Terminal board ass’y) 1 AA
PACKING PARTS
6- 1 CPADBA031JBKZ Bottom pad assembly 1 AS
6- 2 SPAKCA963JBEZ Packing case [AE-X08BE-C] 1 AX
6- 2 SPAKCA964JBEZ Packing case [AE-X10BE-C] 1 AX
6- 2 SPAKCA687JBEZ Packing case [AE-X13BE] 1 AY
6- 3 CPADBA032JBKZ Packing pad ass’y 1 AL
