Sharp AE-X138E User Manual

AH/AU-X108E
AY/AE-X108E
AH/AU-X138E
AY/AE-X138E
3
Models INDOOR UNIT OUTDOOR UNIT
AY-X108E AY-X138E AE-X108E AE-X138E
Cooling capacity kW 2.8 (0.9 3.2) 3.6 (0.9 3.9) 2.8 (0.9 3.2) 3.6 (0.9 3.9)
Heat pump kW 3.7 (0.9 5.0) 4.8 (1.0 6.2) 3.7 (0.9 5.0) 4.8 (1.0 6.2)
Heating capacity
Moisture removal Liters/h 1.1 1.3 1.1 1.3
Electrical data
Phase - Single
Rared frequency Hz 50
Rated voltage range V 198 to 264
Rated voltage V 220 - 240
Rated current Cool A 4.5 - 4.1 6.2 - 5.9 4.5 - 4.1 6.2 - 5.9
Heat A 5.0 - 4.6 7.4 - 6.9 5.0 - 4.6 7.4 - 6.9
Rated input Cool W 930 1220 930 1220
Heat W 1050 1500 1050 1500
Power factor Cool % 94 - 95 89 - 86 94 - 95 89 - 86
Heat % 95 - 95 92 - 91 95 - 95 92 - 91
Compressor Type Hermetically sealed rotary type
Model HV237A1-S15DK
Oil charge 455cc(SUNISO 4GSD)
Refrigerant Evaporator Grooved tube type
system Condenser Corrugate Fin and Grooved tube type
Control Capillary tube
Refrigerant volume 850g 870g 850g 870g
De-Ice system Micro computer controled reverse system
Noise level High dB(A) 39 42 43 48
(at cooling) Med. dB(A) 33 36 - -
Low dB(A) 28 30 - -
Fan system
Drive Direct drive
Air flow High m
3
/min. 10.0 11.0 25.0 26.0
quantity Med. m
3
/min. 6.6 7.4 - -
(at cooling) Low m
3
/min. 5.1 5.9 - -
Fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4" 1/2", 1/4" 3/8", 1/4" 1/2", 1/4"
Drain pipng mm (Inches) O.D ø 18 (45/64)
Others
Safety device Compressor: Thermal protector
Fan motors: Thermal fuse
Fuse, Micro computer control
Air filter Polypropylene net (Washable)
Net Width mm 790 (31-3/32) 728 (28-21/32)
dimensions Height mm 270 (10-5/8) 530 (20-7/8)
Depth mm 188 (7-13/32) 250 (9-27/32)
Net weight kg 9 9 32 39
Note: The condition of star(
) marked item are 'IEC 378'.
