AH/AU-X108E
AY/AE-X108E
AH/AU-X138E
AY/AE-X138E
47
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
CYCLE PARTS
3- 1 CPIPCA443JBK0 Pipe ass'y [AH-X108E/AY-X108E] 1 AZ
3- 1 CPIPCA571JBK0 Pipe ass'y [AH-X138E/AY-X138E] 1 BB
3- 2 PSEN-A004JBK0 Flare nut ass'y 1 AE
3- 3 PSEN-A005JBK0 Flare nut ass'y [AH-X108E/AY-X108E] 1 AG
3- 3 PSEN-A020JBK0 Flare nut ass'y [AH-X138E/AY-X138E] 1 AL
3- 4 PVLV-A082JBE0 Flare union 1 AH
3- 5 PVLV-0406JBE0 Flare union [AH-X138E/AY-X138E] 1 AK
3- 5 PVLV-A083JBE0 Flare union [AH-X108E/AY-X108E] 1 AH
3- 6 DEVA-A073JBK0 Evaporator ass'y 1 BT
3- 7 PPLT-A053JBFA Side cover L 1 AG
3- 8 PPLT-A054JBFA Side cover R 1 AF
3- 9 PSEL-B166JBE0 Eva insulator 1 AE
3-10 PFPFPB329JBE0 Thermo insulator 1 AB
3-11 PCAP-A007JBF0 Nut bonnet [AH-X108E/AY-X108E] 1 AB
3-11 PCAP-A056JBF0 Nut bonnet [AH-X138E/AY-X138E] 1 AC
3-12 MSPR-A131JBE0 Spring 4 AD
3-13 PGID-A072JBE0 Drain guide 1 AE
3-14 PSEL-B121JBE0 Eva insulator 1 AF
3-15 PFPFPB285JBE0 Tube insulator [AH-X108E/AY-X108E] 1 AK
3-15 PFPFPB286JBE0 Tube insulator [AH-X138E/AY-X138E] 1 AH
3-16 PFPFPB414JBE0 Drain sheet 1 AC
ACCESSORY PARTS
4- 1 CRMC-A447JBE0 Remote controller [AH-X108E/AH-X138E] 1 BB
4- 1 CRMC-A442JBE0 Remote controller [AY-X108E/AY-X138E] 1 BB
4- 2 FCOV-A032JBFA Screw cover 2 AL
4- 3 LX-NZ0247JBE0 Special nut 7 AB
4- 4 LX-BZA106JBE0 Special screw 1 AE
4- 5 GLEGGA008JBE0 Anti-vibration rubber 4 AE
4- 6 LPFT-A029JBF0 Drain hose adapter [AY-X108E/AY-X138E Only] 1 AD
4- 7 PPLTNA041JBP0 Mounting plate 1 AP
4- 8 XTTSD45P30000 Long screw 6 AA
4- 9 TINS-A518JBR0 Installation manual 1 AG
4-10 TINSEA199JBR0 Operation manual 1 AH
SCREWS
5- 1 LX-BZA075JBE0 Special screw 1 AA
REF. NO. PART NO. DESCRIPTION Q'TY CODE
