REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST [AU-X108E/AE-X108E]
CABINET AND UNIT PARTS
1- 1 CMOTLA719JBE0 Fan motor [AE-X108E] 1 BG
1- 1 CMOTLA720JBE0 Fan motor [AU-X108E] 1 BG
1- 2 LANGKA059JBP0 Fan motor angle 1 AV
1- 3 PSEL-A904JBE0 Motor angle cushion 1 AB
1- 4 PSEL-A936JBE0 Motor insulator 1 AC
1- 5 PSEL-A978JBE0 Gcon insulator 1 AC
1- 6 PSEL-A979JBE0 Gcon insulator 1 AC
1- 7 CCAB-A187JBK0 Front panel ass’y [AE-X108E] 1 BL
1- 7 CCAB-A189JBK0 Front panel ass’y [AU-X108E] 1 BL
1- 8 GCAB-A148JBFA Front panel 1 AY
1- 9 GGADFA033JBTA Wire fan guard 1 AZ
1-10 PGID-A068JBFA Orifice 1 AQ
1-11 PSEL-B171JBE0 Bulkhead seal 1 AC
1-12 PSEL-B631JBE0 Bulkhead seal 1 AC
1-13 PSEL-B632JBE0 Orifice insulator 1 AC
1-14 PSEL-B633JBE0 Orifice insulator 1 AC
1-15 TLABBA132JBRA Sharp badge 1 AE
1-16 TLABCB083JBR0 Wiring diagram [AE-X108E] 1 AD
1-16 TLABCB086JBR0 Wiring diagram [AU-X108E] 1 AD
1-17 GCAB-A149JBFA Rear cabinet 1 AY
1-18 LHLD-0261JBM0 Cord holder 1 AB
1-19 PSEL-B608JBE0 Air seal 1 AD
1-20 PSEL-B609JBE0 Air seal 1 AD
1-21 CCHS-A643JBTA Base pan ass’y 1 BE
1-22 PSKR-A176JBY0 Bulkhead 1 AT
1-23 PSEL-B540JBE0 Bulkhead seal 1 AG
1-24 RTRN-A235JBE0 Reactor 1 BF
1-25 MSPR-A027JBE0 Thermistor spring 1 AB
1-26 NFANPA056JBE0 Propeller fan 1 AY
1-28 PFTA-A066JBFA Cont. box cover 1 AL
1-29 PPLT-A128JBP0 Protect plate 1 AE
1-30 PSEL-B589JBE0 Cover seal 1 AB
1-31 PSEL-B602JBE0 Cover seal 1 AC
1-33 LHLD-A114JBF0 Thermister holder [AE-X108E] 1 AB
1-34 PPLT-A131JBP0 Rear Plate 1 AK
1-35 PSEL-B606JBE0 Rear plate seal 1 AB
1-36 PSEL-B607JBE0 Rear plate seal 1 AB
1-37 PSEL-B630JBE0 Air seal [AU-X108E] 1 AB
1-38 MSPR-A046JBE0 Protector spring 1 AC
1-39 RTHM-A022JBE0 Thermistor 1 AN
1-40 RTHM-A311JBE0 Thermister ass’y [AE-X108E] 1 AS
1-40 RTHM-A314JBE0 Thermister ass’y [AU-X108E] 1 AQ
1-42 TLABKC227JBR0 Number card [AE-X108E] 1 AC
1-42 TLABKC228JBR0 Number card [AU-X108E] 1 AC
1-43 TSPC-C742JBR0 Name badge [AE-X108E] 1 AE
1-43 TSPC-C747JBR0 Name badge [AU-X108E] 1 AE
CONTROL BOX PARTS
2- 1 CBOX-A021JBW0 Box ass’y 1 AX
2- 2 DSGY-A931JBK0 Printed wiring board [AE-X108E] 1 BN
2- 2 DSGY-A937JBK0 Printed wiring board [AU-X108E] 1 BM
2- 3 LBNDKA084JBW0 Capacitor clamp 1 AE
2- 4 PCOV-A487JBF0 Terminal cover 1 AD
2- 5 PDAI-A067JBW0 Terminal holder 1 AF
2- 6 PDAI-A071JBF0 Heat sink holder 1 AH
2- 7 PDAI-A074JBW0 Capacitor base 1 AH
2- 8 PPLT-A136JBE0 Plate 1 AQ
2- 9 PRDAFA114JBE0 Heat sink 1 AR
2-10 PSEL-B628JBE0 Control box seal 1 AD
2-11 PSEL-B629JBE0 Control box seal 1 AB
2-12 QTAN-A186JBE0 Terminal board 1 AP
2-13 QW-VZD260JBE0 Lead wire 1 AR
2-14 QW-VZD302JBE0 Lead wire 1 AK
2-15 QW-VZD308JBE0 Lead wire 1 AP
2-16 RC-AZA077JBE0 Electrolytic cap. 2 AY
2-17 RFIL-A060JBE0 Ferrite core 1 AF
2-18 RH-DZA117JBE0 Diode bridge 2 AM
2-19 RH-TZA129JBE0 IPM 1 BL
2-20 RTRN-A240JBE0 Reactor 1 AZ
2-22 CCOV-A056JBW0 Cont. box cover ass’y 1 AP
2-23 PSEL-B603JBE0 Cover seal 1 AC
2-24 PSEL-B604JBE0 Cover seal 1 AC
2-25 PSEL-B605JBE0 Cover seal 1 AC
2-26 PSEL-B627JBE0 Cover seal 1 AC
