REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST [AU-X138E/AE-X138E]
CABINET AND UNIT PARTS
1- 1 CMOTLA723JBE0 Fan motor [AU-X138E] 1 BG
1- 1 CMOTLA697JBE0 Fan motor [AE-X138E] 1 BK
1- 2 LANGKA098JBP0 Fan motor angle 1 AP
1- 3 PFPFPB087JBE0 Motor angle cushion 1 AC
1- 4 PGUMSA291JBE0 Damper Rubber 1 AD
1- 5 PSEL-A936JBE0 Motor insulator 1 AC
1- 6 PSEL-B217JBE0 Motor angle cushion 1 AD
1- 7 PBOX-A293JBP0 Reactor box top 1 AL
1- 8 PBOX-A298JBY0 Reactor box 1 AQ
1- 9 PCOV-A482JBP0 Reactor box cover 1 AF
1-10 PSEL-B541JBE0 Reactor box seal 1 AG
1-11 PSEL-B636JBE0 Reactor box seal 1 AC
1-12 QW-VZD249JBE0 Lead wire 1 AH
1-13 RTRN-A236JBE0 Reactor 1 BB
1-14 CCAB-A186JBK0 Front panel ass’y [AU-X138E] 1 BL
1-14 CCAB-A183JBK0 Front panel ass’y [AE-X138E] 1 BL
1-15 GCAB-A148JBFA Front panel 1 AY
1-16 GGADFA033JBTA Wire fan guard 1 AZ
1-17 PGID-A085JBFA Orifice 1 AP
1-18 PSEL-B171JBE0 Bulkhead seal 1 AC
1-19 PSEL-B631JBE0 Bulkhead seal 1 AC
1-20 PSEL-B632JBE0 Orifice insulator 1 AC
1-21 PSEL-B633JBE0 Orifice insulator 1 AC
1-22 TLABBA132JBRA Sharp badge 1 AE
1-23 TLABCB081JBR0 Wiring diagram [AU-X138E] 1 AD
1-23 TLABCB068JBR0 Wiring diagram [AE-X138E] 1 AD
1-24 GCAB-A149JBFA Rear Cabinet 1 AY
1-25 LHLD-0261JBM0 Cord holder 1 AB
1-26 PSEL-B608JBE0 Air seal 1 AD
1-27 PSEL-B609JBE0 Air seal 1 AD
1-28 CCHS-A642JBTA Base Pan ass’y 1 BE
1-29 PSKR-A173JBY0 Bulkhead 1 AT
1-30 PSEL-B540JBE0 Bulkhead seal 1 AG
1-31 RTRN-A257JBE0 Reactor 1 BS
1-32 MSPR-A026JBE0 Spring 1 AB
1-33 NFANPA056JBE0 Propeller fan 1 AY
1-35 PFTA-A066JBFA Cont. box cover 1 AL
1-36 PPLT-A128JBW0 Protect plate 1 AE
1-37 PSEL-B589JBE0 Cover seal 1 AB
1-38 PSEL-B602JBE0 Cover seal 1 AC
1-40 LHLD-A114JBF0 Thermister holder [AE-X138E] 1 AB
1-41 PPLT-A131JBP0 Rear plate 1 AK
1-42 PSEL-B606JBE0 Rear plate Seal 1 AB
1-43 PSEL-B607JBE0 Rear plate Seal 1 AB
1-44 PSEL-B630JBE0 Air seal [AU-X138E] 1 AB
1-45 MSPR-A046JBE0 Protector spring 1 AC
1-46 RTHM-A022JBE0 Thermistor 1 AN
1-47 RTHM-A314JBE0 Thermister ass’y [AU-X138E] 1 AQ
1-47 RTHM-A311JBE0 Thermister ass’y [AE-X138E] 1 AS
1-48 TLABKC226JBR0 Number card [AU-X138E] 1 AC
1-48 TLABKC225JBR0 Number card [AE-X138E] 1 AC
1-49 TSPC-C740JBR0 Name badge [AU-X138E] 1 AE
1-49 TSPC-C701JBR0 Name badge [AE-X138E] 1 AE
CONTROL BOX PARTS
2- 1 CBOX-A017JBW0 Box ass’y 1 AX
2- 2 DSGY-A926JBK0 Printed wiring board [AU-X138E] 1 BN
2- 2 DSGY-A912JBK0 Printed wiring board [AE-X138E] 1 BF
2- 3 LBNDKA082JBW0 Capacitor clamp 1 AD
2- 4 LBNDKA083JBW0 Capacitor clamp 1 AE
2- 5 LBNDKA084JBW0 Capacitor clamp 1 AE
2- 6 PCOV-A487JBF0 Terminal cover 1 AD
2- 7 PDAI-A067JBW0 Terminal holder 1 AF
2- 8 PDAI-A071JBF0 Heat Sink holder 1 AH
2- 9 PDAI-A074JBW0 Capacitor base 1 AH
2-10 PPLT-A135JBE0 Plate 1 AQ
2-11 PRDAFA110JBE0 Heat sink 1 AN
2-12 PSEL-B628JBE0 Control box seal 1 AD
2-13 PSEL-B629JBE0 Control box seal 1 AB
2-16 PSPA-A119JBE0 Cord holder 1 AB
2-17 QTAN-A186JBE0 Terminal board 1 AP
2-18 QW-VZD255JBE0 Lead wire 1 AQ
2-19 QW-VZD256JBE0 Lead Wire 1 AW
2-20 RC-AZA071JBE0 Electrolytic cap. 2 BD
